• Model NO.：GDQH-601
• Pressure vessel：300L 4.0MPa one for each
• Inlet purifying system：EN206 1set
• Drying and purifying system：D48,H48, 4PCS filter 8KG F03 adsorbent, EMER
• High pressure valve：3-365R01,10PCS
• Vacuum gauge：NTS3000, 0-99999PA
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9027809900
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDQH-601 Pressure vessel 300L 4.0MPa one for each Inlet purifying system EN206 1set Drying and purifying system D48/H48, 4PCS filter 8KG F03 adsorbent, EMER High pressure valve 3-365R01,10PCS Vacuum gauge NTS3000, 0-99999PA Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9027809900 Production Capacity 2000PCS/Year

Product Description

Overview

The Test set includes SF6 compressor, vacuum pump, condensation system, liquid storage tank, purification system built-in renewable dry filter, dust filter, ball valve, vacuum gauge, electric system, pressure detection, thermometer, alarm control and instrument panel.

It is suitable for SF6 electrical equipment, GIS manufacturer and institute.


Features

1. SF6 switchgear, GIS gas vacuuming and measurement.

2. Liquefaction tank vacuuming and measurement.

3. Vacuuming for device itself and measurement.

4. Gas Refilled for SF6 switch.

5. Recycle SF6 gas of electric equipment including water treatment and oil treatment.

6. Dry SF6 gas of recycling or refilling and purification treatment.

7. Recycle SF6 gas of SF6 equipment and liquid storage, residual voltage measurement.

8. Storage tank containing 300L volume.

9. Compressing liquid to storage for SF6 gas.

10.Easy to move.


Main Configuration


Name	Model No. And Qty
SF6 Oil-free compressor	5.7M3/H, 50bar, brand UNI,OF-6/50
Reclying vacuum pump	15M3/H, VSV20, FYVAC
Pressure vessel	300L 4.0MPa  one for each
Inlet purifying system	EN206   1set
Drying and purifying system	D48/H48, 4pcs filter     8KG   F03 adsorbent, EMERSON
High pressure valve	3-365R01,10pcs
Vacuum gauge	NTS3000,  0-99999pa
Pressure controller	1piece
Vacuum pump	BSV40,  40M3/H, Ningbo BAOSI
Pressure gauge	1413 filled with liquid,anti-shock 2pcs
Safe valve	YOY---A21H-50P DN15
High pressure hose	3pcs
Connector	4pcs
Rack	1set
Operation panel	1set
