Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Guangdong Komeg Industrial Co., Ltd.

After-sales Service：24 Hours on Line Services
Power Supply：1 Year
Certification：CE, ISO
Warranty：1 Year
Working Chamber Volume (L)：225
Temp. Rate of Change Oc/Min：5

Base Info

Model NO.：ESS-225-C5
Temp. Range：-70oc~+100oc
Temp. Constancy：+,-3.0oc
Interior Material：Stainless Steel Plate(SUS304)
Exterrior Material：Baked Painting Steel or Stainless Steel (SUS304)
Insulation Material：Rigid Polyurethane Foam+Glass Fiber Wool
Compressor：France Imported Tecumseh Semi-Hermetic Compressor
Cooling Mode：Air, Water Cooled
Humidity Range：20~98% Rh
Transport Package：Strong Plywood Case, Meet International Standards
Specification：Standard and Customized
Trademark：KOMEG
Origin：Donguan, China
HS Code：90321000
Production Capacity：1000 Sets Per Yesr

Description

Specifications Model ESS-LL225LL5Working Chamber Volume(L)225Temp Rate of Change( ºC/Min)5Performance -70ºC~+100ºC Rapid Temp Change -40ºC~+85ºC Full Linear ControlHumidity Constancy±0.5ºCTemp Constancy±3.0ºCExterior MaterialCold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless SteelInterior Material Stainless Steel Plate(SUS 304)Insulation MaterialRigid Polyurethane FoamSafety Devicesover pressure,over heat and over current protection for compressor, over temp. protection,CompressorSemi-Hermetic CompressorCooling ModeWater CooledControl systemBalanced Temperature & Humidity Control System(BTC type)HeaterIron-chrome wire heaterBlowerCentrifugal BlowerObservation WindowGlass incorporating heat generatorTemp SensorPt-100 ControllerTouch screen programmable controller Ambient Temp.+5ºC~+35ºCPowerAC 380V/50Hz 3phase 5 wires+ Ground wire Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber

Komeg Rapid Rate Temperature Climatic Chamber Environmental Test Chamber
