Coefficient of Friction Cof Peel Strength Tester China Factory Price
Pubtester Instruments Co., Ltd.- After-sales Service：on Line
- Warranty：12 Months
- Test Item：Coefficient Peel Strength
- Standard：ASTM D 1894
- Capacity Range：5n ,10n, 30n
- Test Accuracy：0.1% Fs
Base Info
- Model NO.：FPT-01
- Displacement Accuracy：0.1mm
- Sled Mass：200g, 500g
- Test Temperature：Room Tem.~99.9 Degree
- Test Speed：0.05 ~ 500 mm,Min (Adjustable)
- Stroke：600mm
- Trademark：Pubtester
- Origin：Shandong, China
Description
Extended ApplicationHigh Temperature Test Coefficient of static and dynamic friction tests at higher temperature than room temperature Wood and Flooring Coefficient of static and dynamic friction tests of wood and flooring Photographic Films Coefficient of static and dynamic friction tests of photographic films Screen of Mobile Phone and Leather Coefficient of static and dynamic friction tests of mobile screens against the leather products Adhesives Peeling test of the adhesive products Medical Adhesives Peeling test of medical adhesives e.g. adhesive bandages and plasters Protection Films Peeling test of protection films for mobile phones or computers Magnetic Cards Peeling test of the films and magnetic cards
Note: *Additional accessories or customized sample grips may need to be purchased separately to complete the tests that cannot be completed with standard sample grips.
** Customized grips are needed for extended applications
Technical Specifications
ISO 37, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T 4850-2002, GB/T 12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB/T 17590, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, JIS P8113, QB/T 2358, QB/T 1130, YY/T 0148, YY0852
Configuration
Standard configuration: Instrument, touch screen, Sled of 200g, sled of 500g, Peel Test Fixture, professional software, communication cable.
Optional configuration: Test board (50×125mm, 40×180mm, 50×200mm), sample cutter(10#,15#,20#,25#,25.4#), standard roller, non-standard grip( with customization), micro printer, calibration weight.
About Us
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. By 2021, Pubtester instruments have been exported to more than 40 countries and areas including UK, Germany, Portugal, Spain, Turkey, Greece, Ukraine, UAE, Saudi Arabia, Tunisia, Nigeria, Morocco, Kenya, Thailand, Malaysia, India, Indonesia, Vietnam, Columibia, Mexico, etc. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time.
FAQ
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 months, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Note: *Additional accessories or customized sample grips may need to be purchased separately to complete the tests that cannot be completed with standard sample grips.
** Customized grips are needed for extended applications
Technical Specifications
| Specifications | FPT-01 |
| Capacity Range | 5N ,10N, 30N |
| Test Accuracy | 0.1% FS |
| Displacement Accuracy | 0.1mm |
| Sled Mass | 200g, 500g (100g,1000g,1814g,2000 are optional) |
| Test Temperature | Room Tem.~ 99.9ºC |
| Drive System | Servo drive system |
| Test Speed | 0.05 ~ 500 mm/min (Adjustable) |
| Accuracy of Test Speed | ±1% |
| Stroke | 600mm |
| Number of Specimens | 1 |
| Max specimen width | 30mm(standard);50mm(optional) |
| Clamping Way | Manual |
| Power supply | AC 220V 50Hz/120V 60Hz |
| Instrument Dimension | 800mm(L)×310mm(W)×300mm(H) |
| Net weight | 50kg |
Standards
ISO 37, GB 8808, GB/T 1040.1-2006, GB/T 1040.2-2006, GB/T 1040.3-2006, GB/T 1040.4-2006, GB/T 1040.5-2008, GB/T 4850-2002, GB/T 12914-2008, GB/T 17200, GB/T 16578.1-2008, GB/T 7122, GB/T 2790, GB/T 2791, GB/T 2792, GB/T 17590, ASTM E4, ASTM D882, ASTM D1938, ASTM D3330, ASTM F88, ASTM F904, JIS P8113, QB/T 2358, QB/T 1130, YY/T 0148, YY0852
Configuration
Standard configuration: Instrument, touch screen, Sled of 200g, sled of 500g, Peel Test Fixture, professional software, communication cable.
Optional configuration: Test board (50×125mm, 40×180mm, 50×200mm), sample cutter(10#,15#,20#,25#,25.4#), standard roller, non-standard grip( with customization), micro printer, calibration weight.
