Automatic Engine Oil Lube Oil CCS Apparent Viscosity Tester (Automatic Injection Type-One Sample)
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Transport Package:Wooden Case or Plywood
- Origin:China
Base Info
- Model NO.:GD-H1088
- HS Code:90318990
- Production Capacity:200PCS,Month
Description
Basic Info.
Model NO. GD-H1088 HS Code 90318990 Production Capacity 200PCS/MonthProduct Description
Automatic Engine Oil Lube Oil CCS Apparent Viscosity Tester (Automatic Injection Type-One Sample)Introduction of Automatic Engine Oil Apparent Viscosity Tester:
The Automatic Engine Oil Lube Oil CCS Apparent Viscosity Tester is mainly used to test the low temperature dynamic viscosity of engine oil.
The Automatic Engine Oil Lube Oil CCS Apparent Viscosity Tester is controlled by computer automatically. Automatic injection, cleaning, calculation of viscosity results.
The Automatic Engine Oil Lube Oil CCS Apparent Viscosity Tester is the most advanced CCS tester in China so far.
Features of Automatic Engine Oil Apparent Viscosity Tester:
1. Automatic testing rotating speed, control current and reduce human error.
2. Semiconductor refrigeration, a large quantity of cold.
3. It adopts imported motor drive, high precision.
4. LCD screen shows all working conditions.
5. Printer can be connected to print the results.
6. After calibration with standard oil, results are automatically calculated.
7. Computer control, windows operating system, all English interface.
8. Improved rotor, low torque test state, high repeatability.
9. Automatically generate calibration curves, direct display of test viscosity results.
10. All test procedures are fully automatic control without manual operation, automatic stop and heat up after the test
11. The instrument automatically recommends the cooling temperature.
12. Rotary encoder detects speed.
13. Viscosity measurement range: 500~15,000CP.
14. It can edit 20 kinds of standard oil results.
15. Equipped with a dedicated low-temperature refrigeration equipment.
Specifications of Automatic Engine Oil Apparent Viscosity Tester:
1 | Applicable standards | GB/T6538, ASTM D2602, D5293 |
2 | Refrigeration method | Semiconductor refrigeration |
3 | Circulation method | Multi-function universal steel pump |
4 | Temperature control mode | digital display PID temperature controller |
5 | Detection method | Automatic injection, automatic cleaning, automatic testing |
6 | Result processing | Automatic storage, printing |
7 | Temperature control range | Normal temperature~-35ºC |
8 | Working power supply | AC220 V, 50Hz |
