Aluminum Alloy Cover Computer Control Electronic Universal Testing Machine
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：24 Hours Technical Supply
- Warranty：12 Months
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Maxcapacity：<1000KN
Base Info
- Model NO.：WDW-10
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：500-1000Kg
- Power Source：AC220V
- Oil Cylinder Position：Top
- Certificaion：CE ISO
- Transport Package：Plywood
- Specification：2CBM
- Trademark：HENSGRAND
- Origin：China
Description
Four-column floor or desk model,
(upper is compression and lower is tensile)Cover All aluminum alloy Control method Computer control Load accuracy Class 1 Class 0.5 Class 1 Class 0.5 Load range 2%~100%F·S 0.2%~100%F·S 2%~100%F·S 0.2%~100%F·S Load resolution 1/300000 Rang of deformation 4%-100%FS Resolution of deformation 0.04um Accuracy of displacement Within±0.5%of indicating load Resolution of displacement 0.01mm Test speed(mm/min) 0.05-1000 stepless arbitrary setting Tensile space(mm) 800(can be customized) Compression space(mm) 800(can be customized) Test width(mm) 400(can be customized) Workbench thickness(mm) 30 Base height(mm) 210 Working environment Room temperature 10ºC~30ºC,relative humidity≤80% Power supply AC220V±10%,50Hz/60Hz(can be customized) Grips Wedge type, plate type and other grips as consumer's demand Dimension(mm) 740*420*1720
(upper is compression and lower is tensile)
