• Model NO.：GW-079D
• Accuracy Grade：1
• Load Way：Mechanical Load
• Loading Method：Dynamic Load
• Display：Needle
• Control：Manual Control
• Weight：0-100Kg
• Power Source：Manual Operation
• Oil Cylinder Position：Manual Operation
• Packaging：Wooden Case
• Export Markets：Global
• Model No：Gw-079d
• Measuring Range：Hre
• Standard：ISO, ASTM, GB,T, Bsen
• Suitable for：Production Site, Sales Site or Construction Site
• Measure Range：Equivalent to 20~110hre
• Transport Package：Wooden Case
• Specification：280X230X80mm
• Trademark：Great Win
• Origin：China
• HS Code：90241020
• Production Capacity：500 Sets,Year

Basic Info.

Model NO. GW-079D Accuracy Grade 1 Load Way Mechanical Load Loading Method Dynamic Load Display Needle Control Manual Control Weight 0-100Kg Power Source Manual Operation Oil Cylinder Position Manual Operation Packaging Wooden Case Export Markets Global Model No Gw-079d Measuring Range Hre Standard ISO, ASTM, GB/T, Bsen Suitable for Production Site, Sales Site or Construction Site Measure Range Equivalent to 20~110hre Transport Package Wooden Case Specification 280X230X80mm Trademark Great Win Origin China HS Code 90241020 Production Capacity 500 Sets/Year

Product Description

W-20A Webster Hardness Equipment (GW-079D) Equipment discription:

In addition to producing many Aluminum construction profiles, but also produce a variety of industrial profiles. Some large-tonnage production of extrusion profiles with cross-section of industrial complex, wide, thick features. Industry profiles are often used as force beam, so its very high hardness requirements. Webster Hardness Tester Universal jaw width of only 6.5mm, can only measure the thickness of 6mm the following sections. For more than 6mm thick industrial profiles, can not be achieved before the rapid measurement of the hardness of the site.

In response to these problems, we developed the material used to measure the thick-type W-20A Webster hardness tester, the jaw width increased to 13.5mm, measurable 6 ~ 13mm thick aluminum, the hardness of plate or pipe. This instrument adds a called "anvil seat cover" of accessories. Calibration of "anvil seat cover" set to the anvil seat, according to the method of general-purpose instrument calibration equipment. After calibration, with "Anvil seat cover" measurable 1 ~ 6mm thick material, remove the "Anvil seat cover" measurable 6 ~ 13mm thick material.

Calibration points: 1, the "anvil seat cover" set to the anvil seat. 2, rotating "anvil seat cover" so that "anvil seat cover" the direction of the arrow upward. 3, W-20 type apparatus according to the calibration step in calibration of instruments.

Technical parameter:


Measuring  range	0-20HW
Accuracy	0.5HW
Measuring  range	Equivalent  to  20~110HRE
Sample  size/diameter	Thickness  ≤ 13plate, diameter  ≥ 10  pip
Weight	0.5kg
Weight	1.1kg
Dimension	280× 230× 80mm

What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.

What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.

What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.

What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
