• Model NO.：KU-1000S
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Capacity(Kw)：15
• Chamber Volume(L)：1000
• Inner Size (D*W*H))：100*100*100(Cm)
• Cooling Mode：Water Cooled
• Exterior Material：Stainless Steel Plate
• Transport Package：Plywood Case
• Specification：Standard and customs made
• Trademark：KOMEG
• Origin：China
• HS Code：90321000
• Production Capacity：100-500kg

Temperature range hot zone

+60°C to +200°C



Temperature range cold zone- 80°C to -10°CAmbient temp

-65°C to +150°C



Pre-heating time

+60ºC~+200ºC, Within 20 min



Recovery time

High-Temp Exposure 30 min



Recovery time

Low-Temp Exposure 30 min



Recovery time

Recovery time within 5 min



Safety device

NFB(No fuse breaker), over pressure, over heat and over current protection



compressor, over temperature protection, over load protection for blower, dry

heat protection

Standard accessory

Cable port(portΦ50mm)*1, shelves*2
