• Model NO.：SX2672
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Measuring Current：10A-30A
• Measuring Range：20~500m Ohm
• Transport Package：Carton or Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030332000
• Production Capacity：100 Units

Items

Model

SX2672

Measuring Range mΩ

Measuring Current A

25.0~30.0 A

20.0~ 150.0  mΩ

10.0~25.0 A

20.0~ 199.9  mΩ

4.0~10.0  A

20.0 ~ 500   mΩ

 Intrinsic Error

±(3%r+3d)

Measuring Current

A

4.0 ~ 30.0

Intrinsic Error

±(3%r+3d)

Test Voltage (AC) V

≤6

Alarm Resistance mΩ

Resolution

0.1

1.0 ~ 199.9  mΩ

1

200 ~ 500  mΩ

Measuring Time s



Note: 0 is continuous measuring, that means the measuring time is infinite.

Overall L×W×H, mm:

380×320×145

Weight   kg

9



Warranty: One year quality guarantee after shipment.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
