• Model NO.：DR502LN
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Motor Drive
• Weight：0-100Kg
• Power Source：AC220V
• Height of Brush：2-12mm
• Diameter of Movement：40mm
• Range：1-9999
• Pressure：490cn,590cn,780cn
• Sample Size：112.8mm
• Trademark：DARONG
• Origin：China
• HS Code：9024800000
• Production Capacity：2000sets,Month

Basic Info.

Model NO. DR502LN Accuracy Grade 1 Load Way Electronic Load Loading Method Static Load Display Digital Control Motor Drive Weight 0-100Kg Power Source AC220V Height of Brush 2-12mm Diameter of Movement 40mm Range 1-9999 Pressure 490cn/590cn/780cn Sample Size 112.8mm Trademark DARONG Origin China HS Code 9024800000 Production Capacity 2000sets/Month

Product Description

]DR502LN  Apparels fabric circular locus pilling and abrasion testing equipment
[ Scope of application ]
Used for the determination of pilling and pilling of all kinds of wool fabrics, chemical fiber pure spinning, blending, knitting, woven fabrics and other textiles.

[Related standards] GB/T4802.1
[Instrument characteristics
1, scientific no-turning mechanical structure, smooth rotation, suitable for long time continuous operation;
2, nylon brush with a hot treatment technology processing molding, will not scratch the sample cloth;
3, ergonomic design, comfortable operation of the test staff.
[ Technical parameters ]
1, number of work stations: 2 (1 pilling, 1 fuzzing)
2. Pilling trajectory: a circular trajectory with a diameter of 40mm.
3. Adjustable brush: nylon brush with adjustable height is adopted.
4, sample pressure: chemical fiber fabric pressure is 590cN;
The pressure of worsted fabric is 780cN;
The pressure of carded fabric is 490cN.
5 sample specifications: diameter 112.8mm round, area of 100 square centimeters.
6. Number :(1 to 99999) preset.
7. Relative movement speed of gripper and grinding platform :(20-70)r/min (speed can be set by the user)
8. Power supply: AC220V±10% 50Hz 500W
9. Size: 500mm×400mm×300mm (L×W×H)
10. Weight: about 25kg



Technical parameters]

Diameter of movement	Counting range	Height of brush
40mm	1-9999	2-12mm
