• Model NO.：GD-07008
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Na
• Item Name：ASTM D2843 Smoke Density Tester
• Applicable Standards：ASTM D2843, DIN 4102
• Application 1：Measure The Smoke Density of Burning and Decomposi
• Test Principle：Test Loss of Light Transmission in Testing Chamber
• Cabient Material：Stainless Steel
• OEM Service：Yes
• Training：Your Technicals Can Get Free Training in Our Facto
• Installation：We Can Send Our Engineers for Installation
• Warranty：1 Year
• Transport Package：Packed in Veneer Case
• Specification：Refer to detailed description
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：10 Sets, Month

Basic Info.

Model NO. GD-07008 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Na Item Name ASTM D2843 Smoke Density Tester Applicable Standards ASTM D2843, DIN 4102 Application 1 Measure The Smoke Density of Burning and Decomposi Test Principle Test Loss of Light Transmission in Testing Chamber Cabient Material Stainless Steel OEM Service Yes Training Your Technicals Can Get Free Training in Our Facto Installation We Can Send Our Engineers for Installation Warranty 1 Year Transport Package Packed in Veneer Case Specification Refer to detailed description Trademark GOLD Origin Chongqing, China HS Code 9031809090 Production Capacity 10 Sets/ Month

Product Description

ASTM D2843  Smoke Density Tester
Introduction:
In a fire, people are smothered by smoke or can't escape because they can't see the way.The smoke density tester for building materials meets the technical requirements specified in national standard GN/ t8627-2007. It can be used to measure and describe the reaction of materials, products and components to heat and flame under controlled laboratory conditions, and to measure the static smoke production of building materials under experimental conditions of combustion or decomposition.
International Standards:

1. ASTM D2843
2. GB/T 8627:2007,GB 8624:2012
3. DIN 4102:B1

Features:

1. User- friendly, environment-friendly, patented design;
2. All steel structure, heavy duty, there is a 25x230mm ventilation opening at the bottom , and with a 1700L/min ventilation system;
3. With a toughened glass viewing window which is convenient for viewing;
4. Equipped with main and auxiliary burner enable enough smoke after fully burning;
5. High voltage pulse automatic ignition device;
6. Precise pressure adjustment valve for gas control;
7. 64*64mm square stainless specimen support;
8. 300mm optical path;
9. With adjustable light source system, and light receiving system with imported silicon optical amplifier, which make the result stable and accurate;
10. 19 inch standard control cabinet;
11. controlled by PC+Labview software;
12. Can input the flame appearing time, extinguished time, specimen burning end time, etc. after testing. Accuracy +/- 0.1s;
13. Can output test result file automatically;
14. Can automatically acquire, calculate, save and output test data;
15. Real-time display the data as well as smoke density curve
