• Model NO.：SXFA-IV
• Loading Method：Dynamic Load
• Display：Needle
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Output：0~100vrms,5arms,10A
• Transport Package：Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Units

Output0~180Vrms,12Arms,36A(peak value)Voltage measurement precision±0.1%CT Turns RatioRange1~400001~30000Precision±0.05%±0.1%PT Turns RatioRange1~400001~30000Precision±0.05%±0.2%Phase measurementPrecision±2min±5minResolution0.5min0.5minSecondary Winding ResistanceRange0~300Ω0~300ΩPrecision0.2%±2mΩ2%±2mΩAC load measurementRange0~300VAPrecision2%±0.2VAPower SupplyAC220V±10%,50HzWorking ConditionsTemperature: -10^οC~50^οC, Humidity: ≤90%Size & Weight365 mm×290 mm×153mm    Weight<10kg
Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
