2 Zone Basket Type Cold Hot Thermal Shock Chamber Lab Stability for Electronic

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V
  • Certification：CE, TUV, ISO
  • Warranty：1 Year
  • Interrior Material(W*H*D)：3900*2100*4300mm
  • Volume(M3)：35.2cbm
  • Exterior Material(D*W*H)Mm：5050*2350*4500

Base Info

  • Model NO.：KMHW-17
  • Temp. Constancy：+,-0.5oc
  • Humidity Constancy：+,-2.5%R.H.
  • Temp. Uniformity：+,-2.0oc
  • Door Size：Single Wing:W80*H180;Double Wing:W160*H180
  • Controller：Touch Screen Controller
  • Operation Mode：Setting, Program
  • Standard Accessories：No Fuse Breaker, Over Pressure, Over Heat and Over
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets,Year

Description

Capacity(L)64L ,72L ,100L ,200L , 300L ,500L(A/B/D)
 Low Tempeature chamberA : -55ºC~ -10ºC B: -70ºC ~ -10ºC D: -80ºC ~ -10ºC
 Pre-heat time+60ºC~+200ºC within 25 min
 Test chamberA : -40ºC~ +150ºC B: -55ºC ~ +150ºC D: -65ºC ~ -150ºC
 Temperature Accurcy±0.5ºC
 Temperature Uniformity±2.0ºC
 Temperature Recovery Time≤5min;
+150ºC:15 Min;
-55ºC:15 Min;
Sample Weight:10kg Aluminum Material
 AccessoriesTesting Cord Hole: 1*50mm;
Testing Shelf: 2;
Testing Blanket:1 with 10kg capacityStand and WheelStands: 4pcs adjustable for chamber standing;
Wheels: 4pcs adjustable for moving the chamber
