Ess Rapid Temperature Change Test Chamber for PV Module Solar Cell Module

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V
  • Certification：CE, TUV, ISO
  • Warranty：1 Year
  • Interior Dimensions (D*W*H)：1600*500*1000mm
  • Exterior Dimensions(D*W*H)：2240*1500*1600mm
  • Heater Power：15kw+1kw

Base Info

  • Model NO.：HL-160-NS
  • Max. Temp：35oc or 50oc
  • Volume：800
  • Air Compressor：2HP
  • Transport Package：Strong Plywood Case for Long Journey Delivery
  • Specification：Standard and customized, ISO9001, SGS, CE, TUV, UL
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

Temperature range

-40ºC- +150ºC

Temp Deviation<=±2.0ºCTemp Fluctuation±0.5ºCPre-heat timeFrom-40ºC up to +80ºC nonline 3ºC/min (no load )Pull down rate

From+80ºC down to -40ºC nonline 3ºC/min (no load )

Door windowglass incorporating heat generatorObservation windowWith observation window(Specific size based on design )electric insulation coated glass prevent condensation effectivelyTemp sensor Pt 100 Platinum resistance Cable port

Φ50mm*1 located on each side of chamber, with rubber stopper and stainless steel cover

CompressorGerman Bock /Bizr hermetic compressorRefrigerantEnvironmental-friendly refrigerant: R404A ,R23 comply with Environmental rules safe and non-toxicCondenserShell and Tube condenser(Water -cooled)EvaporatorFin-type multi-stage automatic load capacity adjustment, No frost in long-term use of low temperature and humidity conditionsEss Rapid Temperature Change Test Chamber for PV Module Solar Cell ModuleEss Rapid Temperature Change Test Chamber for PV Module Solar Cell ModuleEss Rapid Temperature Change Test Chamber for PV Module Solar Cell Module
