ASTM D4541 Standard Pull-off Adhesion Tester
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Type：Adhesion Testing
- Transport Package：Aluminum Alloy and Carton Box
- Specification：ASTM D4541
- Trademark：ctech
- Origin：China
Base Info
- Model NO.：SR-LTF
- HS Code：90248000
- Production Capacity：500 Set,Month
Description
Basic Info.
Model NO. SR-LTF HS Code 90248000 Production Capacity 500 Set/MonthProduct Description
Pull-off adhesion tester1. Standards ISO4624, ASTM D4541 and ASTM D7234.
2. Consists of Actuator, Load sensors, LCD display device, Dolly (Φ10, Φ14, Φ20 and Φ50), Cutting tool (Φ10, Φ14, Φ20 and Φ50), Caking agent and Computer software.
3. Technical parameter
Maximum pressure: 25kN/S(MPa)
Accuracy: 0.5%.
Features:
1. Serial communication port:
Communicate with the computer through RS-232 serial communication port through which stored test data can be transmitted to the computer. Test results can be printed out by the provided software.
2. Sensor input port:
Through shielded wire of sensor and straight load sensor to measure adhesion force.
3. Zero adjustment potentiometer:
allow to manually adjust the initial value of sensor to zero.
4. Calibration potentiometer: calibrate the sensor
