• Model NO.：KU SERIES
• Inner Size (D*W*H))：100*100*100(Cm)
• Cooling Mode：Water Cooled
• Exterior Material：Stainless Steel Plate
• Transport Package：Plywood Case
• Specification：Standard and customs made
• Trademark：KOMEG
• Origin：China
• HS Code：90321000
• Production Capacity：100-500kg

Specifications ModelKU-1000SInner Size (D*W*H)mm1000*1000*1000Capacity(KW)18Chamber Volume(L)1000PerformanceTemp range-70ºC~+150ºCTemp constancy±0.5%Temp deviation≥100ºC, ±3.0ºC(at constant pressure with empty load)<100ºC, ±2.0ºC(at constant pressure with empty load)Cooling rate0.7ºC~1.0ºC/min(Overall average)Pressure rangeConstant pressure ~1kPaPressure constancyWhen ≥40kPa, ±2kPa, 4kPa~40pKa ±0.5kPa, when≤4kPa, ±0.1kPaDepressurization rateConstant pressure~1kPa≤30mins(Normal temp)Pressure recovery rate10kPa/Min(adjustable)MaterialExterior materialCold-rolled steel sheet(Rust proof&Plastic Spray treated)/Stainless Steel plateInterior materialStainless steel(SUS304)Pressurized partsHigh quality steel plate(Rust proof & Plastic spray treated)Insulation materialHigh quality glass woolCooling SystemCompressorSemi-Hermetic CompressorCooling ModeWater cooledTemp regulating methodBalanced Temperature & Humidity Control System (BTHC)PumpRotary vane type vacuum pumpHeaterIron-chrome wire heaterSight windowCircular viewing glass incorporating heat generatorTemp SensorPt-100ControllerTouch Screen ControllerSafety DevicesOver pressure, over heat and over current protection for compressor, over temp. protection, over load protection for blower, Hydraulic and Water lack Protection, leakage protection, phase-lack protection, Pump failure alarmStandard AccessorySight window, Cable Port( 1 located on the left side), Baffle, Baffle frame*2PowerAC380V/50Hz, 3Phase 5 wires+ Ground Wire.

Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
