50kV/5kVA Gas Insulated AC Hipot Test Equipment
HV Hipot Electric Co., Ltd.- Type：Withstand Voltage Test Set
- Maxcapacity：0-300kv
- Accuracy Grade：1.5%
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：GDYD-M
- Control：Manual Control
- Weight：100-500Kg
- Power Source：AC220V
- Input：AC220V ± 10%
- Frequency：50Hz,60Hz ± 1Hz
- Output：0-50kV, AC RMS
- HV Source：SF6 gas (Gas type testing transformer)
- Output control：Manual control
- Voltage accuracy：≤1.5% (F.S)
- Current Accuracy：≤1.5% (F.S)
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030332000
- Production Capacity：2000PCS,Year
Description
Basic Info.
Model NO. GDYD-M Control Manual Control Weight 100-500Kg Power Source AC220V Input AC220V ± 10% Frequency 50Hz/60Hz ± 1Hz Output 0-50kV, AC RMS HV Source SF6 gas (Gas type testing transformer) Output control Manual control Voltage accuracy ≤1.5% (F.S) Current Accuracy ≤1.5% (F.S) Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Specification
| Input | AC220V ± 10% |
| Frequency | 50Hz/60Hz ± 1Hz |
| Output | 0-50kV, AC RMS |
| Working Duration | 100%Rated-1minute, 50%-continuous |
| Capacity | 5kVA (based on selectable) |
| HT Source | SF6 gas (Gas type testing transformer) |
| Output control | Manual control |
| Voltage accuracy | < 1.5% (F.S) |
| Current Accuracy | < 1.5% (F.S) |
| Timing range | 0-99H |
| Metering | Digital display, kV meter: Digital display, kV meter: AC 0-50kV, mA meter: AC 0-100mA |
| Humidity | 85% RH |
| Environmental temperature | -20ºC~50ºC |
| Weight Control unit | About 20kg |
| Dry testing transformer | About 45kg |
