• Model NO.：TFG2922A,2924A,2932A,2934A,2942A,2944A
• Weight：7.0kgs(Tfg29X2a) 10.0kgs(Tfg29X4a)
• Certificate：Ce RoHS ISO9001
• Interface：USB Host,USB Device,LAN and WiFi
• Screen：7′′ Touch Screen Display
• Transport Package：Carton
• Specification：363*154*327(TFG29X2A) 363*154*467(TFG29x4A)
• Trademark：SUIN
• Origin：China
• HS Code：854320909
• Production Capacity：30, 000 Sets,Year

 TFG2922ATFG2924ATFG2932ATFG2934ATFG2942ATFG2944ACHANNEL242424FrequencySine1μHz ~ 200MHz1μHz ~ 300MHz1μHz ~ 400MHzSquare1μHz ~ 120MHzPulse1μHz ~ 80MHzRamp1μHz ~ 6MHzOthers1μHz ~ 50MHzResolution1μHzAccuracy±1ppmWaveformType165 kinds include:sine,  square,  ramp,  pulse,  noise,Arbitrary waveforms and user-definedSample Rate1.2GSa/sVertical Resolution14bitsArbitrarySaple Rate1μSa/s~200MSa/sLength2-32M pointsResolution14bitsSquareRise/Fall time≤2.5nsDuty Cycle0.01%~99.99%PulseRise/Fall Time2.5ns~1.2sWidth4ns~(1000000s-4ns)Sine Spectral PurityTotal Distortion≤0.2%(20Hz~20kHz,20Vpp)Phase Noise<-140dBc@10MHz(0dBm,10kHz offset )Amplitude(into 50 Ω)≤40MHz1mVpp ~ 10Vpp≤100MHz1mVpp ~ 5Vpp≤200MHz1mVpp ~ 2Vpp≤300MHz1mVpp ~ 1.5Vpp>300MHz1mVpp ~ 1VppAccuracy±(1% of setting +1mVpp),(Sine 1kHz,0V offset,≥10mVpp)OffsetRange±5Vpk ac+dc(50Ω load)Accuracy±(1% of setting +2mV+0.5% of amplitude)(High-Z)Modulation TypeFM,AM,PM,PWM,Sum,FSK,4FSK,NFSK,PSK,4PSK,NPSK,ASK,OSKBurst Burst Count1 to 100 000 000 cyclesGeneral CharacteristicsPowerAC 100 ~ 240V, 45 ~ 65Hz, <70VA(TFG29X2A),<80VA(TFG29X4A)Dimension & Weight364×155×329 mm, 7.0 KGs (TFG29X2A)364×155×468 mm, 10.0KGs(TFG29X4A)Standard AccessoriesOptionsPower Cord1Frequency Counter(upper limits to 3GHz)
OCXO(accuracy;±0.01ppm±1μHzBNC cable1CD(Software+User's Guide)1Wifi Antenna1About SUIN
Shijiazhuang SUIN Instruments Co., Ltd is a high-tech company and concentrates on R&D, production, test, sales and service of test & measurement instruments, electrical products, application software, etc.
