Automatic Wax Oil Melting Tester, Cooling Curve Method
Xiangtan Xiangyi Instrument Limited- Power Supply:AC220V±10% 50Hz
- Temperature Range of Cooling Bath:16ºC~28ºC
- Bath Temperature Accuracy:±0.1ºC
- Sensor:Ptl00 Thermal Resistance
- Transport Package:Plywood Packing
- Specification:530*450*600
Base Info
- Model NO.:PT-D2539-184A
- Trademark:Xiangyi
- Origin:China
- HS Code:90318090
- Production Capacity:100 PCS,Month
Description
Basic Info.
Model NO. PT-D2539-184A Trademark Xiangyi Origin China HS Code 90318090 Production Capacity 100 PCS/MonthProduct Description
PT-D2539-184A Automatic Wax oil melting tester, cooling curve methodThis instrument complies with GB/T2539 and is suitable for the determination of the melting point of paraffin wax, but not for microcrystalline wax and petroleum grease. The instrument adopts PLC industrial touch screen, HMI man-machine interface, configuration network, mobile phone or computer remote control. The operation of the instrument is simple. You only need to place the sample, the instrument automatically starts testing, displays and stores the test results, and can be printed out or exported by U disk.
- Degree of automation: Industrial-grade ARM32-bit chip core processor, which automatically completes the test process. Support online monitoring and downloading, making it more convenient to use.
- Control system: Industrial-grade PLC programmable logic controller is adopted, and the three anti-paint treatments make the instrument peace of mind. With a 7-inch tablet touch screen, you can complete the test according to the screen prompts without training.
- Operating system: WindowsCE embedded operating system, full Chinese operation interface, arbitrary switching of pages, simple and convenient operation, automatic printing of results, large-capacity storage function, can store tens of thousands of data and curves.
- Safety performance: automatic diagnosis, over-temperature alarm and automatic cut-off of heater power supply, test completion alarm function.
- Data input/output: RS485 connection standard, USB2.0 interface can be connected.
Specifications
Model | PT-D2539-184A |
Power supply | AC220V±10% 50Hz |
Power supply | 1200 W |
Ambient temperature | 10~30ºC |
Temperature range of cooling bath | 16ºC~28ºC |
Bath temperature accuracy | ±0.1ºC |
Sensor | Ptl00 thermal resistance |
Temperature test accuracy | ±0.01ºC |
Working mode | This instrument is designed with two holes and can measure 2 samples at the same time |
Refrigeration method | compressor refrigeration |
Ambient temperature | 10~35ºC |
Relative humidity | ≤85% |
Dimensions | 530*450*600 |
Weight | 25kg |
Packing list
No | Name | Unit | Qty |
1 | Automatic paraffin melting point tester | pc | 1 |
2 | Rubber stopper | pcs | 2 |
3 | Test tube | pcs | 2 |
4 | printer paper | roll | 1 |
5 | Sensor | pcs | 2 |
6 | power cable | pc | 1 |
7 | fuse | pcs | 2 |
8 | user's Guide | copy | 1 |
9 | Product certification | copy | 1 |
10 | warranty card | copy | 1 |
