• Model NO.：HJ-66
• Weight：0-100Kg
• Power Source：AC220V
• Drop Height (mm)：400~1500, 400~2000
• Machine Weight (Kg)：600, 700
• Test Load (Kg)：0~70
• Drop, Lift Method：Electric
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-66 Weight 0-100Kg Power Source AC220V Drop Height (mm) 400~1500, 400~2000 Machine Weight (Kg) 600, 700 Test Load (Kg) 0~70 Drop, Lift Method Electric Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

It is suitable for the drop impact strength test of packaging products such as electronic products, plastic products, toy products, and metal products. This machine simulates the damage of packaged products when they are dropped during transportation, loading and unloading, and evaluates the impact resistance of the packaged parts and the rationality of the packaging design. This machine conducts vertical impact test on the transport package by free fall. The test piece can be freely selected in advance for the drop test in three states: face, edge and corner. The drop height can be preset. When the test piece reaches the preset height, it can be automatically positioned and the drop height Can be preset.

Features:
This machine can perform free drop test on the surface, corner and edge of the package. It is equipped with a digital display height indicator and a decoder for height tracking, so that the drop height of the product can be accurately given, and the error with the preset drop height does not exceed 2% or .10mm. The machine adopts a single-arm double-column structure, with electric reset, electric control drop and electric lifting devices, which is easy to use; the unique hydraulic buffer device greatly improves the service life, stability and safety of the machine. The double-arm setting can easily place the product, and the angle error between the impact surface of the drop angle and the plane of the bottom plate is less than or equal to 5°.


Drop height (MM)	400~1500, 400~2000
Dimensions (MM)	W1200*D1400*H2200, W1200*D1400*H2700
Machine weight (KG)	600, 700
Test null (MM)	W800*D600*H800
Test load (KG)	0~70
Drop, lift method	Electric
Display method	Digital display, adjustable
Test method	Faces, edges and corners fall in all directions
Drop backplane media	Pure solid steel plate
Drive mode	Motor driven
Using electric	AC three-phase five-wire 380V50HZ

The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
