GDYZ-301A High sensitivity Zinc Oxide Surge Arrester Tester with facotry price
HV Hipot Electric Co., Ltd.- After-sales Service：yes
- Warranty：1 year
- Mass Scope of Workpiece：11kg
- Type：Auto Testing Machine
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：GDYZ-301A
- Display：Digital
- Power Source：AC220V
- Oil Cylinder Position：no
- Input resistance of current channel：≤1Ω
- Action times of monitor：0 ~ 99 times
- Weight of main unit：4kg (without accessories)
- Measurement resolution (Voltage)：0.001V
- Measurement resolution (Current)：0.001mA
- Measurement resolution (Angle)：0.001°
- Battery working time：Main unit 8 hours, voltage sampling box 12 hours
- Wireless transmission distance：1000 meters and above (empty and Unobstructed)
- Dimension of main unit：320*270*140mm
- Hand-held collection probe：180*120*80mm
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV HIPOT
- Origin：Wuhan China
- HS Code：9030820000
- Production Capacity：9000 Sets,Year
Description
4kg (without accessories)
Accessories
Accessories
| Main unit | 1piece |
| Sampling unit | 1piece |
| Wireless communication unit | 1piece |
| Sensing board | 1piece |
| Accessory case | 1piece |
| Measurement cable of 3-phase resistive current | 1piece |
| Sampling cable of 3-phase voltage | 1piece |
| Output cable of current meter calibration | 1piece |
| Communication cable | 1piece |
| Ground cable | 1piece |
| Power cable | 1piece |
| Charger | 1piece |
| Fuse | 3pcs |
| Print paper | 1roll |
