IEC60529 Ipx56 Test of Rain and Storm Simulation Rain Test Chamber
Dongguan Xin Bao Instrument Co., Ltd.- Flow Rate of The Weter：0.07L,Min +5%
- Speed of Spray Swing Pipe：IP3 15 ,Min;IP4 10,Min
- IP1/ 2 Dripping Hole：0.4mm
- Rain Pressure：80~400kpa Adjustable
- Speed of Turntable Rpm：1~10 Adjustable
- Controller：Programmable Color Display Touch Screen Controller
Base Info
- Model NO.：XB-OTS-P
- Power：Electronic
- Material：SUS 304 Stainless Steel
- Transport Package：Standard Strong Wood Case
- Specification：W*H*D800*800*800mm(Customized)
- Trademark：OTS
- Origin：Guangdong, China (Mainland)
- HS Code：9031200000
- Production Capacity：268 Set,Month
Description
ModelXB-OTS-800P XB-OTS-1000P Internal Dim.W×H×D(mm) 800×800×800 1000×1000×1000 External Dim.W×H×D(mm) 1250×1800×1100 1750×1850×1300 Water Temp. Normal Normal Spray Type Total Water
Flow
(L/min) R1 1.8 IP×1 With in 1~1.5mm/min(In drip box) R2 3.2 IP×2 With in 3~3.5mm/min(In drip box) S1 24.5 IP×3 angle±600,R:400mm,1.1L/min S2 39.2 IP×4 angle±1800,R:400mm,1.8L/min Pressure of
spray nozzle
(kgf/cm*2) R1 0.1 1.Flow rate of the water=0.07L/min 2.1P×3,Radius:400mm,16Number or open holes=16,total water flow:1:1L/min. R2 0.3 3.1P×4,Radius:400mm,25Number or open S1 1 holes=25,total water flow:1:8L/min. S2 3 *Radius:200mm,R400mm. (For 1P×3,1P×4 only) (RPM)Test Specimen Frame 17RMP 1RPM Spray Nozzle Rotation Speed 23RPM Promote the pipe on both sides of the vertical line of 30 °
each time back and forth about four seconds to promote Swing 60 ° from vertical for 4 seconds at one time Promote the pipe on both sides of the vertical line of 180 °
for about 12 seconds to promote one round Swing 180 ° from vertical for 12 seconds at one time Material Interior SUS#304 Exterior Other Components Chamber lamp.Wiper Chamber lamp.Wiper,casters with Adjusters casters with Adjusters Power Source(K.W.) AC 1Ψ 220V 60/50Hz 4KW
Use:
Waterproof test system is according to IEC60529, IEC60598, IEC60335 and IEC 60034-5:2000. The IP-X includes the following test grades: IPX1, IPX2, IPX3, IPX4, IPX5, IPX6, IPX7 and IPX8 (Refer to page 51 of IEC60529). It is widely used in the authentication test organization for the products such as electrical & electronic products such as LED luminaires as well as in the relevant quality control department for the waterproof detection of the enclosures protection grades.Recommend ProductsCompany Profile
Manufacturing TechniqueCustomer PhotosCertificationsPacking&ShipingFAQ1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers. If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2.What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3.Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4.How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly. Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
