225kVA/25kV PD-free AC Series Resonant Test System
HV Hipot Electric Co., Ltd.- Model number:GDTF-225kVA,25kV
- Rated capacity:225kVA
- Input power supply:Single phase 415V, 50Hz
- Rated voltage:25kV
- Rated current:9A
- Working frequency:50Hz
Base Info
- Model NO.:GDTF-225kVA,25kV
- Delivery time:7-30 days
- Transport Package:Vacuum Package
- Specification:ISO, SGS
- Trademark:HV Hipot
- Origin:Wuhan China
- HS Code:9030899090
- Production Capacity:5000 Sets,Year
Description
Basic Info.
Model NO. GDTF-225kVA/25kV Delivery time 7-30 days Transport Package Vacuum Package Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 5000 Sets/YearProduct Description
General information
GDTF(L)-225/25 is specially designed for AC withstand voltage test of power generators, also can be considered as power source of PD & DDF Test for 0.4-1.2µF, 24kV Generator Stator Windings. The capacitance of single phase to ground is 0.4-1.2uF, test frequency is 50Hz and test voltage is no more than 24kV. Testing time is 15mins.System Composition
PD-free Excitation Transformer APSJL-27kVA/3kV/0.4kV 1set
PD-free Insulation Transformer APSGL-27kVA/415V/415V 1set
PD-free Resonant Control Unit APSTF(L)-27kVA/415V 1set
PD-free Adjustable Reactor APSDK(L)-225kVA/25kV 1set
PD-free AC Voltage Divider APSFR-30kV 1set
PD-free Compensating Capacitor APSBC-30kV 1set
Specification
Rated capacity | 225kVA |
Input power supply | Single phase 415V; 50Hz |
Rated voltage | 25kV |
Rated current | 9A |
Working frequency | Power frequency 50Hz |
Outout voltage waveform distortion rate | ≤0.5% |
Working time | continuous working of 15min under rated load. (Please kindly notice: The interval time between each lot of tests should be at least 30min. Which means the whole test system should be 15min On/ 30min Off.) |
Temperature rise | ≤65K after continuous working of 15min under rated load |
Quality factor | Q ≥10 |
Accuracy | 1.5% (RMS) |
Protective function | over-current, over-voltage and flashover protections for test object. |
Partial discharge amount | ≤5PC |
