• Model NO.：GD-H1087
• Circulation Method：Multifunctional Universal Plastic Steel Pump
• Temperature Control Mode：Digital Display Pid Temperature Controller
• Detection Method：Automatic Testing
• Result Processing：Automatic Storage and Printing
• Temperature Control Range：Normal Temperature~-35c
• Transport Package：Wooden Case or Plywood
• Origin：China
• HS Code：9031809090
• Production Capacity：200PCS,Month

Basic Info.

Model NO. GD-H1087 Circulation Method Multifunctional Universal Plastic Steel Pump Temperature Control Mode Digital Display Pid Temperature Controller Detection Method Automatic Testing Result Processing Automatic Storage and Printing Temperature Control Range Normal Temperature~-35c Transport Package Wooden Case or Plywood Origin China HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

Automatic ASTM D5293 Engine Oil Cold-Cranking Simulator for Apparent Viscosity Test


Introduction of  Cold-Cranking Simulator:
The Automatic ASTM D5293 Engine Oil Cold-Cranking Simulator mainly tests the low temperature dynamic viscosity index of the engine oil.
The Automatic ASTM D5293 Engine Oil Cold-Cranking Simulator is fully controlled by the computer and the viscosity result is automatically calculated.


Features of Cold-Cranking Simulator:

1. Automatically detect the rotational speed and control current to reduce human error.
2. Semiconductor refrigeration, large cooling capacity.
3. It adopts the imported motor drive, high precision.
4. The LCD screen shows all working status.
5. It can connect to the printer to print the results.
6. Automatically calculate results after calibration with standard oil.
7. Microcomputer control, Windows operating system, full Chinese/English interface.
8. Improved rotor, low torque test state, high repeatability.
9. Automatically generate a calibration curve, directly display the test viscosity results.
10. All test processes are fully automatic control, no manual operation is required, the test stops automatically and the temperature rises.
11. The instrument automatically recommends the cooling temperature.
12. The rotary encoder detects the rotational speed.
13. Viscosity measurement range: 1500~15,000CP.
14. It can edit dozens of standard oil results.
15. Equipped with special low temperature refrigeration equipment.


Specifications of Cold-Cranking Simulator:


1	Applicable standards	GB/T6538, ASTM D2602, D5293
2	Refrigeration method	Semiconductor refrigeration
3	Cycle mode	Multi-function universal steel pump
4	Temperature control mode	digital display PID temperature controller
5	Detection method	Automatic test, automatic temperature rise
6	Result processing	Automatic storage, calculation
7	Temperature control range	Normal temperature ~-35ºC±0.03
8	Working power supply	AC220 V, 50Hz
