Walk in Environmental Condition Temp Humidity Test Chamber IEC Standard

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V
  • Certification：CE, TUV, ISO
  • Warranty：1 Year
  • Height Range(Cm)：30-200
  • Maximum Sample Weight(Kg)：100
  • Maximum Sample Size(Cm)：100*80*100

Base Info

  • Model NO.：KPD-320
  • Base Area Size(Cm)：170*120*2
  • Motor Power(kVA)：0.85
  • Exterior Size of Tester(Cm)：170*120*250
  • Net Weight (Kg)：600
  • Applicable Standards：ISO02248-1972(E)
  • Transport Package：Strong Plywood Case, Meet International Standard
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

Main technical parameters ( water-cooled, temperature +25ºC, no load)



1.Temperature range

-70ºC ~ +180ºC(Different temperature range per customer requirements)



2.Temperature deviation±2.0ºC3.Temperature fluctuation<=1.0ºC4.Temperature uniformity<=±2.0ºC

5.Heating up rate&Cooling down rate



from 25ºC

The temperature performance test is based on the relevant provisions of the IEC 60068 -3



standard; the sensor is placed at the unit air outlet.

Chamber structure



The test chamber adopts the overall structure, the upper part is the working chamber, the rear side is



the refrigeration unit, the lower right space (>=700mm) is vacant to install the hydraulic part device, the



right is the electric control cabinet, the control panel is located on the right front side; the width direction



opens the door , the right side is the air duct system; the air supply motor, the centrifugal fan blade, the



heater, and the evaporator.
