Double Zone Individual Control Environmental Test Chamber for New Energy
Guangdong Komeg Industrial Co., Ltd.- Power Supply：380V
- Certification：CE, TUV, ISO
- Warranty：1 Year
- Working Chamber Volume (L)：225L
- Temp. Rate of Change Oc/Min：10
- Temp. Range：-70oc~+100oc(Rapid Temp. Change -40oc~+85ocfull Li
Base Info
- Model NO.：ESS-408LL5
- Temp. Constancy：+,-3.0oc
- Heater：Iron-Chrome Wire Heater
- Compressor：France Imported Tecumseh Semi-Hermetic Compressor
- Blower：Centerifugal Blower
- Power：AC380+,-10% 50Hz 3phase4wires+Groud Wires
- Standard Accessories：Sight Window, Cable Port, Baffle, Baffle Frame*2
- Control System：Balanced Temperature & Humidity Control System
- Transport Package：Strong Plywood Case, Meet International Standard
- Specification：Standard and Customized
- Trademark：KOMEG
- Origin：Dongguan, China
- HS Code：90321000
- Production Capacity：1000 Sets,Year
Description
1. Temperature
1.1 Temp. range
-70ºC~+150ºC
1.2 Temp. deviation
≤±2.0ºC
1.3 Temp. fluctuation
±0.5ºC
1.4 Heating up rate
From -40ºC to +85ºC, linear, >=200ºC/h, with load of 300kg, No Heat Emission
1.5 Cooling rate
From -40ºC to +85ºC, linear, >=200ºC/h, with load of 300kg, No Heat Emission
2. Floor capacity
300KG/m2
3. Full load
10 PV Modules to be loaded in a vertical orientation.
Single panel max. size of 2000*1000*50mm.
Total weight of 300KG.
