• Model NO.：KU-504S
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Top
• Capacity(Kw)：16
• Chamber Volume(L)：504
• Inner Size (D*W*H))：80*70*90(Cm)
• Custom Made：Yes
• Compressor：Danfoss or Tecumseh
• Transport Package：Plywood Case
• Specification：Standard and customs made
• Trademark：KOMEG
• Origin：China
• HS Code：90321000
• Production Capacity：100-500kg

Main technical parameters ( water-cooled, temperature +25ºC, no load)

-70ºC ~ +180ºC(Different temperature range per customer requirements)

5.Heating up rate&Cooling down rate

from 25ºC

The temperature performance test is based on the relevant provisions of the IEC 60068 -3

standard; the sensor is placed at the unit air outlet.

Chamber structure

The test chamber adopts the overall structure, the upper part is the working chamber, the rear side is

the refrigeration unit, the lower right space (>=700mm) is vacant to install the hydraulic part device, the

right is the electric control cabinet, the control panel is located on the right front side; the width direction

opens the door , the right side is the air duct system; the air supply motor, the centrifugal fan blade, the

heater, and the evaporator.

1.Chamber size

Inner size: W 1800 × H 1200 × D 1200 mm



Outer size :W 2935 × H 2170 × D 1450 mm approx
