• Model NO.：HJ-69
• Display：Drop Test Machine
• Weight：0-100Kg
• Power Source：AC220V
• Test Space：Calculated by Customer Product
• Test Height：0~1000mm Can Be Set Freely
• Test Aspects：Edge, Angle, Face
• Working Power：380V,50Hz
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-69 Display Drop Test Machine Weight 0-100Kg Power Source AC220V Test Space Calculated by Customer Product Test Height 0~1000mm Can Be Set Freely Test Aspects Edge, Angle, Face Working Power 380V/50Hz Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

The zero drop tester is mainly used to evaluate the impact of the packaged parts on the impact of drop during the actual transportation, loading and unloading process, and to evaluate the impact resistance strength of the packaged parts during the transportation process and the rationality of the packaging design. The zero drop tester is mainly used for the drop test of larger packages.

Features:
Mainly used for larger package drop test. The zero-drop test machine uses an "E"-shaped fork that can move down quickly as a specimen bracket, and the tested goods are placed and balanced according to the test requirements (surface, edge, and angle test). During the test, the pallet moved downward at a high speed and was separated from the test piece. Before the tested packaged goods fell to the bottom plate, the "E" fork was embedded in the bottom plate under the action of the high-efficiency shock absorber. In theory, there is zero drop. The testing machine can perform drop test from zero height range.


Maximum weight of test piece	160(kg)
Test space	Calculated by customer product
Test height	0~1000mm can be set freely
Test aspects	Edge, angle, face
Working power	380V/50HZ
Drive mode	Motor driven
Protective device	There are induction protection devices on the top and bottom
Impact plate material	45# steel, solid steel plate
Height display	LED digital display, and adjustable altitude stop function

The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
