• Model NO.：HJ-56
• Display：Lock Test Machine
• Weight：0-100Kg
• Power Source：AC220V
• Voltage：AC220V,50Hz
• Working Radius (Arm Length)：700mm
• Beat Period：25,305,25
• Installation Method：Formal, Wall, Flip
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-56 Display Lock Test Machine Weight 0-100Kg Power Source AC220V Voltage AC220V/50Hz Working Radius (Arm Length) 700mm Beat Period 25/305/25 Installation Method Formal, Wall, Flip Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Introduce
The intelligent electronic lock life durability test device is used to conduct APP temporary key opening, fingerprint opening, key opening, Bluetooth opening, password opening, magnetic card opening and other simulated use behavior tests for electronic anti-theft locks and other products. Intelligent electronic lock life durability test The device uses the current advanced DELTA six-axis robot as the driving simulation to restore the actual unlocking scene. The entire structure of the mechanical arm is a space joint type with multiple degrees of freedom, which can accurately position the electronic lock under test. The mechanical arm is made of hard aluminum alloy material and is a hollow tube structure, which can not only ensure high rigidity of the arm, but also reduce the weight of the arm and the load of the motor. The control system sets and controls the action sequence of the servo motor by PLC, and has both timing and counting functions. The inductive switch of the mechanical arm detects the status of each working point, and judges the quality of the electronic lock of the sample, so as to make corresponding deal with.

Features
1. The multi-dimensional operation of the six-axis robot can realistically simulate the movements of human arms and fingers;
2. Use highly elastic silicone instead of fingers to unlock fingerprints, with a wide range of fingerprints and a more realistic simulation effect;
3. Various types of anti-theft electronic locks, smart electronic locks, fingerprint locks and other products can be tested in one system
4. The system can test samples 24 hours a day without manual duty, which greatly improves the detection efficiency;
5. With power-off protection function, the test can be continued without manual intervention after power-on;
6. It can record the times and time of the switch experiment;
7. It has the functions of experiment times preset and experiment time preset;
8. With the function of experiment completion and error alarm;
9. One-time investment, low maintenance cost in the later period, and free software upgrade for life, which reduces the testing cost of the experiment;
10. The main components of the equipment, such as the drive motor, touch screen, PLC, frequency converter, force sensor, data acquisition card and other key components should be internationally renowned brands to improve the grade and reliability of the equipment and meet the requirements of relevant tests;
11. The accuracy requirements of various technical parameters such as equipment voltage, current, temperature, force value, frequency, etc. meet the requirements of CTL-251B


Six-axis robot payload	≤6Kg
Working radius (arm length)	700mm
Repeatability	±0.02 mms
Beat period	25/305/25
Installation method	Formal, Wall, Flip
Rated voltage	220 V a.c. 50/60 Hz
Rated power	1.5kW
Testing frequency	0~99999999 times can be preset
Test frequency	0~20 times/min
Control and operation	PLC intelligent program + TFT LCD touch screen operation  (with industrial computer control)
Device power	AC220V 50/60Hz



The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
