Mil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, Z

Ai Si Li (China) Test Equipment Co., Limited
  • Power Supply：AC380V
  • Certification：CE, TUV, ISO, SGS BV
  • Warranty：1 Year
  • Moving Coil Size：Dia. 150 mm
  • Vibration Wave：Sine, Random, Shock
  • Frequency Range：1Hz to 3500Hz

Base Info

  • Model NO.：ES-40
  • Max. Acceleration：1000m,S2
  • Max. Speed：2.0m,S
  • Impact Displacement：51mm
  • Moving Coil Weight：6.5kg
  • Transport Package：Wood Export Case
  • Specification：Customized
  • Trademark：ASLI
  • Origin：China
  • HS Code：85141090
  • Production Capacity：500sets Per Month

Description

ModelRated Sine Force (N)Rated Random Force (N)Frequency Range (Hz)Rated Acceleration (m/s2)Rated Speed (m/s)Rated displacement (p-p)mmMax. Loading (Kg)moving coil (Kg)Dimension of Moving coil (mm)ES-3300030003-350010001.6251003.5Φ150ES-3a300030003-35004001.6401209Φ230ES-6600060003-350010001.6251806.5Φ230ES-6a600060003-350010001.65125012Φ230ES-1010000100003-300010001.85127014Φ240ES-2020000200003-300010001.85130030Φ320ES-3030000300003-280010001.85l45040Φ450ES-4040000400003-280010001.85150050Φ450ES-5050000500003-270010001.85175050Φ450

Mil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, ZMil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, ZMil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, Z
Mil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, ZMil-Std 810f Sine and Random Vibration Test System 3 Axis X, Y, Z

Welcome our new and regular customers visit our factory with Electromagnetic Vibration 3 Axis Test Shakers  price, and any inquiries please feel free to contact us !
