• Model NO.：GD-2131L
• Certification：ISO9001
• Customized：Customized
• Color：Gray
• Power supply：AC220V; 50Hz
• Output voltage：DC 0-16kV (adjustable)
• Rated power：1kVA
• Max. energy：1024J, 8UF
• DC flashover voltage：32kV
• DC flashover current：63mA
• Max. impulse current：500mA
• Discharging method：DC HV, one time, cycle
• Cycle discharge time：3-6 seconds
• Delivery time：Shipped in 20 days after payment
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：1000 Sets,Year

Basic Info.

Model NO. GD-2131L Certification ISO9001 Customized Customized Color Gray Power supply AC220V; 50Hz Output voltage DC 0-16kV (adjustable) Rated power 1kVA Max. energy 1024J, 8UF DC flashover voltage 32kV DC flashover current 63mA Max. impulse current 500mA Discharging method DC HV, one time, cycle Cycle discharge time 3-6 seconds Delivery time Shipped in 20 days after payment Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 1000 Sets/Year

Product Description

Product Description

It's used to generate HV impulse when using impulse flashover method to detect high impedance fault.


Features

• Strong burning ability, max.burning power is 1000W, breakdown point can be burned in short time and the resistance of breakdown point is decreased.
• If working together with GD-4133 Cable Fault Tester, there are two locating ways:
  a.Low voltage pulse: If only using GD-4133, open circuit and low impedance grounding faults of cable can be located, and the length of cable can be measured or wave speed of cable can be detected.
  b. High voltage flashover: The discharging pulse voltage waveform of fault point is sampled by discharging sphere gap, which can locate fault distance.
• Generate impulse of fixed frequency. If working together with GD-4132 Cable Fault Locator, there are following functions:
  a. Audio frequency: locate high impedance, flash-over faults.
  b. To pinpoint cable's route, identify special cable.
  c. To metallic breakdown(dead grounding), using magnetic-field measurement to locate accurately.
• It also can be used in DC HV withstand test.

Specifications


Input power supply	AC 220V, 50Hz
Output voltage	DC 0-16kV (adjustable)
Rated power	1kVA
Max. energy	1024J, 8uF
DC flash-over voltage	32kV
DC flashover current	63mA
Max. impulse current	500mA
Discharging method	DC HV, one time, cycle
Cycle discharging time	3-6 seconds
Environmental temperature	0-40ºC
Humidity	<75% RH
Altitude	<1000m
Insulation level	A
Dimension	430*540*410mm
Weight	31kg
