Factory Price Underground Cable Fault Locating System GD-2136L
HV Hipot Electric Co., Ltd.- Connectors：USB
- Test Mode：One-sided Test
- Usage：Power Cable Tester
- Test Region：Forming Cable
- Cable Type：Shielded
- Power：Electricity
Base Info
- Model NO.：GD-2136L
- Certification：ISO
- Customized：Customized
- Color：Yellow
- Rated power：1kVA
- Insulation degree：A degree
- Power supply：AC 220V, 50Hz
- Output voltage：DC 0~ 16kV
- Environment humidity：<75%RH
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：China
- HS Code：9030332000
- Production Capacity：1000PCS,Year
Description
GD-2133 Cable Fault Detector
It can test faults of short circuit, grounding, high impedance leakage, high impedance flashover fault and cable's poor connection, disconnection for all kinds of power cables (voltage degree 1kV-35kV), local cable, communication cable, coaxial-cable and metal overhead line. It also can measure cable's length and propagation speed of electric wave speed on the cable.
Features
Safe, prompt and accurate testing. It uses LV impulse method and HV flashover detection, which test all kinds of cable faults.
Using high speed data sampling technology. A/D sampling speed is 100Mhz.
Wave form and data automatically display on big LCD screen.
Wave form and parameter storage function.
Function of comparing testing waveform of cable fault with normal waveform.
Wave form extending function.
Directly show fault point and testing point direct distance or relative distance.
Modify speed of propagation any time according to different testing cables.
Built-in rechargeable battery. Small size, portable to carry.
Specifications
