• Model NO.：HJ-68
• Weight：0-100Kg
• Power Source：AC220V
• Gas Distribution：0.4-0.6MPa
• Relative Humidity：<80
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-68 Weight 0-100Kg Power Source AC220V Gas Distribution 0.4-0.6MPa Relative Humidity <80 Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Mooney viscometer is a method of measuring the fluidity of raw rubber and unvulcanized rubber by rotating. In the process of rubber processing, from the start of the plasticizer to the completion of vulcanization, it is closely related to the fluidity of the rubber, and the Mooney viscosity value is an important technical indicator to measure this performance. It is an indispensable instrument in the reclaimed rubber, rubber, wire and cable industries, and is widely used in measurement and quality inspection; rubber research; automobile manufacturing; wire and cable; medical equipment; civil aviation; ; tire production.

Features of Mooney Viscometer

This machine complies with the requirements of GB/T 1232 "Determination of Mooney Viscosity of Unvulcanized Rubber", GB/T1233 "Determination of Mooney Viscometer Method of Initial Vulcanization Properties of Rubber Compounds" and ISO289, ISO667 and other standards. The viscosity, scorch and vulcanization index of the rubber compound. Microcomputer control, data display, automatic calibration, it is an ideal experimental instrument for rubber industry and scientific research units. Imported intelligent digital temperature control instrument is adopted, which is easy to adjust and set, and has a wide temperature control range. The microcomputer adopts imported chips, with high reliability, and all data can be automatically calculated and printed.

Parameters of  Mooney Viscomee

Temperature measurement range	0--200ºC
Temperature measurement accuracy	≤±0.3ºC
Control precision	≤±0.3ºC
Temperature resolution	0.1ºCE
Torque range	0-100 Mooney value
Calibration accuracy	100±0.5 Mooney value
Rotor speed	2±0.02 r/min
Ambient temperature	0--35 ºC
Relative humidity	<80
Test pressure	11.5KN ±0.5KN
Gas distribution	0.45-0.6MPA
Power supply	220V 1KVA
Machine size	About 660×570×1300mm
Machine weight	About 210Kg



The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
