• Model NO.：HJ-69
• Display：Lock Test Machine
• Weight：0-100Kg
• Power Source：AC220V
• Voltage：AC220V,50Hz
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-69 Display Lock Test Machine Weight 0-100Kg Power Source AC220V Voltage AC220V/50Hz Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

This machine is suitable for smart lock (fingerprint) (swipe card) to open and close the door (each opening method can be replaced), and it has reached the test of the smart lock repeatedly. Overview The lock body durability tester is a special testing instrument used to test the life of the lock. The testing department uses it to sample the quality of the products of the enterprise that produces the lock. The test result is an important basis for judging whether the lock is qualified. The lock is installed during the test. on the tester.

Parameters of  Single-station intelligent lock life testing machine

Overall dimensions	Length (1100mm - 1400mm), Width (1100mm - 1400mm), Height  (2100mm - 2500mm)
Simulate door frame size	Length (2000mm - 2400mm), Width (1000mm - 1300mm), Note: 2100mm * 1100mm (European standard)
Analog door weight	100KG
Working environment temperature and humidity	Temperature between -10ºC~40ºC, humidity≤85%RH
Equipment working voltage	220VAC
Rated power consumption of the whole equipment	≤800W
Air supply input standard air pressure	0.25-0.6MPa
Test station	Single station
Simulate door opening direction	open right
Test steps support large number of programming steps	≥15 steps

The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.


FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
