CE Certified Programmable Temp. and Humidity Test Equipment

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hours on Line Services
  • Warranty：12 Months
  • Type：Climate Testing Equipment
  • Weight：100-500Kg
  • Power Source：AC380V
  • Control System：Touch Screen

Base Info

  • Model NO.：KMH-408R
  • Temperature Humidity Range：Programmable Temperature and Humidity
  • Temp. Range：-40oc~+150oc or -140of~+302of
  • Humidity Range：20-98%R.H.
  • Temp. Constancy：+,-0.5oc
  • Humidity Constancy：+,-2.5%R.H.
  • Equipment Power：14.5kw
  • Total Power：16kw
  • Max Current：35.3A
  • Heater：6kw
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：CE, SGS
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets,Year

Description


ModelKMH-408R408L chamber volumeTemp. range -20°C ~150°C Display resolution0.1°CTemperature stabilityHigh±0.5°C ,low ±1.0°CTemperature uniformity ±2.0°CHeat up time -20°C ~+100°C,within 35 minPull down time +20°C ~-20°C,within 45 minHumidity range20~98%R.H,(standard),   '10~98%R.H,(with humidifier)Humidity constancy±2.5%R.HHumidity uniformity±5.0%R.HInterior Dimension(mm)700W*700H*480D Exterior Dimension(mm)980W*1940H*1740DInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolTotal power  10.6KW(heater 6KW included)Max current35.3AWater Consumption2.5L/hrAmbient Temp.+5°C ~+35°C Power Supply AC 380V±10%50Hz ,3 phase 4 wires +Ground WiresWeight 450KGSight window size460*560mmSample holder 2 pcsFittingscable port(portΦ50mm)*1, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker,over pressure,over heat&over current protect,over temp. protect, over load protect for blower, dry heat protect Control SystemBalanced Temperature & Humidity Control (BTHC)SystemRefrigeration systemAir Cooled (Water Cooled is option)Hermetic compressor  Hermetic compressor
Single stage refrigeration system
CFC-Free refrigerant(HFC-507/HFC-23)Controller7-inch LCD Touch Screen panel                                                                        Operation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
