• Model NO.：WAW series
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Power：1.5kw
• Host Structure：6 Pillars
• Transport Package：Standard Export Wooden Box
• Trademark：C-Tech
• Origin：Hebei, China
• HS Code：90248000
• Production Capacity：1000PCS,Year

CodeWAW-100BWAW-300BWAW-600BWAW-1000BMax load capacity(kN):1003006001000Structure typeUnderneath oil cylinder, Four stand column, double screw, Protect cover,
Coil spring buffer deviceAccuracy classClass 1(0.5)Test force range1%-100% F.STest force accuracy±1%(±0.5%)Measuring range of extension1%-100% F.SExtension accuracy±1%(±0.5%)Displacement accuracy±1%Displacement resolution0.001mmRelative error of stress-controlled velocity±2%(±1%)Speed setting accuracy±1%(±0.5%)Adjusting range of strain-controlled velocity0.00025/s-0.0025/sRelative of force/extension/displacement-control±2%(±1%)Range of force/extension/displacement-control0.3%-100% F.SRelative error of force/extension/displacement-control≤1%Maximum speed of sentre sill (mm/min)320Compression space(mm)500600600600Tensile space (mm)600700700700Piston stroke (mm)200200200200Diameter of round specimen (mm)Dia. 6-22Dia.10-32Dia.13-40Dia. 14-45Thickness of flat specimen (mm)0-150-200-200-40Maximum distance of bending test (mm)300300300300Size of compression plates(mm)Dia.110Dia. 150Dia. 200Dia. 225Dimension (load frame mm)800×620×1850800×620×1900800×620×2000900×700×2300Dimension (control console mm)800×600×1600Power380V, 50Hz, 2.2kWWeight (load frame kg)300300300300Weight (control console kg)1450160019002600
