• Model NO.：HJ-56
• Weight：0-100Kg
• Power Source：AC220V
• Light Source：Analog D65
• Integrating Sphere：Diameter 150mm
• Show：128X32 DOT Matrix LCD Display
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-56 Weight 0-100Kg Power Source AC220V Light Source Analog D65 Integrating Sphere Diameter 150mm Show 128X32 DOT Matrix LCD Display Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Introduce
The whiteness tester is a special instrument for measuring the whiteness of objects. It is widely used in papermaking, printing, textile printing and dyeing, building materials, chemical industry, food, salt making and other industries and other production and commodity inspection departments that need to measure the whiteness of objects.

Features of Whiteness Tester
1. Advanced circuit design effectively guarantees the accuracy and stability of measurement data
2. The instrument has a power-off protection function, and the calibration data will not be lost after power-off
3. The instrument is equipped with a standard RS232 interface, which can communicate with computer software (sold separately)

Parameters of  Whiteness Tester

Voltage	AC(100~240)V, (50/60)Hz, 50w
Working environment	Temperature (10~35)ºC, relative humidity≤85%
Show	128x32 dot matrix LCD display
Light source	Analog D65
Integrating sphere	Diameter 150mm
Sample size	Test plane≥φ30mm, thickness≤40mm
Zero drift	≤0.1
Indication error	≤0.5
Repeatability error	≤0.02 (10 consecutive tests with an interval of 10 seconds)
Specular error	≤0.1
Print	Thermal printer
Communication Interface	RS232 (optional)
Dimensions	365×260×425mm
Instrument net weight	About 12kg



The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.

FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
