• Model NO.：JBDW-300,450,600,750CY
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Computer
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：None
• Impact Speed：5.24,M
•  Specimen Bearer Span：40mm
• Transport Package：Standard Export Packing
• Trademark：HST OR OEM
• Origin：China
• HS Code：9024101000
• Production Capacity：800 Sets Per Month

JBDW-450CYJBDW-600CYJBDW-750CY Control MethodComputer Controlled Max. impact energy300J450J600J750J Impact speed5.24m/s Pre-rising angle of the pendulum150° Angle accuracy±0.1° Specimen bearer span40mm Round angle of the jawR1.0~1.5mm Round angle of impact edgeR2.0~2.5mm(R8mm) Angle of impact edge30° Thickness of impact knife16mm Capacity of sample box20 pcs Cooling waycompressor refrigeration Range of low temperatureRoom temperature~ - 60°C / - 80°C / - 100°C Precision of controlling temperatureFluctuate±0.5ºC, Grades 1ºC The distance between the
pendulum shaft and impact  point750mm Standard specimen dimension10 x 10 (7.5 or 5) x 55mm Pendulum300J 1pc450J 1pc600J 1pc750J 1pc Power supply3-phase 4-line 380V 50Hz



Dear customers, for more informations please send enquiry directly to Sunny:
Jinan Hensgrand Instrument Co., Ltd
ADD: NO. 4915, West Jingshi Road, Jinan 250012, PR CHINA.



Website: http://hsttest.en.made-in-china.com
