• Model NO.：HJ-68
• Weight：0-100Kg
• Power Source：AC220V
• Determine The Maximum Load：2kg
• Minimum Resolution：0.1g
• Minimum Fine-Tuning Distance：0.01mm
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-68 Weight 0-100Kg Power Source AC220V Determine The Maximum Load 2kg Minimum Resolution 0.1g Minimum Fine-Tuning Distance 0.01mm Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

The switch load displacement curve testing machine is suitable for all kinds of buttons and switches (load-displacement)
Curve, test, use the WINDOWS Chinese window screen to set, the operation is simple and convenient, and all
All data can be stored (test conditions, displacement curves, life curves, inspection reports - etc.)
S205 button-switch load displacement curve testing machine adopts servo motor drive, which can provide high-precision
(Load-displacement) measurement, you can get a completely accurate button and switch curve test.

S205 key-switch load displacement curve testing machine features:
PEAK FORCE, RETURNFORCE, DISTANCE and CLICK rates can be directly
Display the value on the graph without manual calculation.
The measurement curve is memorized by the computer and can be enlarged or reduced at any time. A piece of A4 paper can be
It is intended to specify the placement of N graphs.
The upper and lower specification values of the measurement items can be input, and the measurement results can be automatically judged as OK or NO.
The maximum measuring stroke and load can be input, and the computer is automatically controlled.
The test report can be converted into EXCEL and other document report formats.
The inspection report can be generated automatically, no need to input again.
The content of the header of the inspection report can be modified at any time.
The test conditions are all set by the computer screen, which is convenient and fast.
The test data is stored in the hard disk. (Each data can be stored, unlimited times)
The computer directly prints and stores the force-displacement curve graph and checks the report. (unnecessary
Graph paper, usually A4 paper)
The load unit display N, Ib, g, kg can be switched freely.


Determine the maximum load	2kg
minimum resolution	0.1g
Maximum measuring height	100mm
Minimum fine-tuning distance	0.01mm
Measuring speed range	0-100mm/min
Transmission mechanism	Ball screw rod
drive motor	Panasonic Servo Motor
physical dimension	300*270*500(W*D*H)mm
weight	31Kg (machine)
power supply	AC110V or 220V



FAQ
1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,we offer 12 months for the FREE maintenance, while considering of sea transportation,If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem,we can send you new spare parts or provide on-site repair.

2.. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
