Automatic AC Motor Comprehensive Test Bench
Sansion Power Electric Co., Ltd.- Type:Strength Testing Machine
- Maxcapacity:<1000KN
- Accuracy Grade:0.5
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:Digital
Base Info
- Model NO.:SXDJ
- Control:Manual,Auto at Customized
- Weight:500-1000Kg
- Power Source:at Customized
- Oil Cylinder Position:Under
- Control Mode:Manual,Computer
- Transport Package:Plywood Case
- Specification:ISO9001 SGS
- Trademark:Sansion
- Origin:Wuhan, China
- HS Code:9030339000
- Production Capacity:1000 Units
Description
Basic Info.
Model NO. SXDJ Control Manual/Auto at Customized Weight 500-1000Kg Power Source at Customized Oil Cylinder Position Under Control Mode Manual/Computer Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030339000 Production Capacity 1000 UnitsProduct Description
General Information:The SXDJ is applied for ex-work and after maintaining testing on AC motor, DC motor and variable frequency motor with which capacity of 0-10000KW and voltage degree 0-10KV.
The system is integrated with industry PC, power source system, controlling system, sensor, signal adjusting module, data sampling hardware & software, numerical computing software, graphical display & operation software, test report generating, waveform & measuring results storage and printing software.Features:
√ Fully English interface, auto printing, easy to operate.
√ Motor AC hipot testing part is portably designed, easy to move.
√ For HV motor of capacity 630KW-9000KW, voltage 6KV-10000V, it is needed to be equipped with 10KV booster, 10KV HV CT/PT and etc.
Specification:
Main Testing Items:
√ Electric Strength
√ Measuring condition
√ Insulation Resistance
√ Cold Resistance
√ Low Starting Current
√ Locked-rotor Current
√ No-Load Power
√ No-Load Current
√ Leakage Current
√ Turn-To-Turn Insulation
Please contact us Sansion Power for further information. Thank you!
