• Model NO.：GDYD-BX-12
• Weight：36kg
• Power Source：AC220V
• output voltage：AC 0-10kV
• capacity：2kVA
• current：AC 0-200mA
• Transport Package：Standard Export Plywood Case
• Specification：ISO9001
• Trademark：HV HIPOT
• Origin：Wuhan, China

Basic Info.

Model NO. GDYD-BX-12 Weight 36kg Power Source AC220V output voltage AC 0-10kV capacity 2kVA current AC 0-200mA Transport Package Standard Export Plywood Case Specification ISO9001 Trademark HV HIPOT Origin Wuhan, China

Product Description

One Piece Design GDYD-BX-12 AC Hipot Test Set 10kV 2kVA


I. General information

AC hipot testing is the effective and direct way to test insulation strength for electrical equipment, apparatus or machines. It checks dangerous flaws which assure electrical equipment continuous working.
Typical applications include testing of transformers, switchgear, cables, capacitors, aerial motors platforms, hot sticks bucket bricks, vacuum bottles and other related equipment like vacuum interrupters, blankets, ropes, gloves, hydraulics hose, instruments transformers generators.


II. Features


1. Monitoring function: HV voltage, HV current, LV current, zero position indicator, power indicator, work indicator, timing indicator
2. Protection function: over current protection, zero start protection, sound and light alarm reminder
3. New type time relay is adopted, and the timing range is wider (1S~99H)
4. The use of a new type of current relay is more accurate and reliable to ensure the safety of people and equipment.
5. The high-voltage coil of the test transformer is a cylindrical multi-layer tower type, wound by high-quality polyester enameled wire and high-voltage insulation material.
6. Light weight, small size, convenient movement and superior performance.

III. Specifications

Input	AC220V ± 10%
Frequency	50Hz/60Hz ± 1
Output voltage	AC 0-10kV
LV current	0-10A
Capacity	2kVA
HV current	0-200mA
Output control	Manual control
Voltage accuracy	≤ 3% (F.S)± 1digital
Current Accuracy	≤ 3% (F.S)± 1digital
Timing	0-99H
Weight	26kg
Humidity	85% RH
Environmental temperature	-20ºC~50ºC
Size	430*540*410 mm

IV. Working Principle


This device is composed of a contact voltage regulator, control circuits, protection circuits, measurement circuits and signal circuits. It is by connecting to the power frequency power supply and adjusting the voltage regulator (that is, the input voltage of the test transformer) to obtain the required test high voltage voltage value.
