Precision Digital Spring Testing 20-500n
Shanghai Trisun Parts Manufacture Co., Ltd.- Max Diameter of Workpiece：3mm~10mm
- Mass Scope of Workpiece：1 Kg
- Type：Tensile & Compression Tester
- Maxcapacity：20 N~500 N
- Accuracy Grade：0.001,0.01 N
- Load Way：Electronic Load
Base Info
- Model NO.：ZJ50N
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
- Weight：88kg
- Power Source：AC220V
- Oil Cylinder Position：No
- Protective Function：Program, Machinery Double Protection
- Speed Range：0.01-500mm,Min
- Electronic Hand Wheel (Find Adjustment)：0.01mm,Grid
- Tensile and Compression Test Space (mm)：190
- Compression Plate Diameter (mm)：30,60
- Displacement Sensor Brand：Japan Omron
- Force Sensor Brand：America Celtron
- Grade of Testing Machine：Grade 0.5
- Min. Reading Value of Test Force：0.001n, 0.01n
- Transport Package：Conform to The Standard of Machinery Jb,T 6147
- Specification：480*380*655mm
- Trademark：Trisun, Nuetral or customised
- Origin：Made in China
- HS Code：9024101000
- Production Capacity：10000 Sets,Year
Description
±1.0%Relative error of test force zero point ±0.1% Relative error of indicating value repeatability of test force ±1.0% Resolution of displacement 0.01mm Error of displacement indicating value ±(50+0.15L)μm Dynamical system AC digital servo system Driving system Synchronous pulley, double nut ball screw Data processing Auto-acquisition and processing, can save, query and print. Parallelism error of up and down pressure plate ≤0.05mm Size of testing machine 480mm × 380mm × 655mm Weight of testing machine 60kg Noise ≤50dB(A)
