ASTM D 2863 Plastics Elevated-Temperature Loi Testing Equipment

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Item Name：ASTM D 2863 Plastics Elevated-Temperature Loi
  • Standard：ASTM D2863
  • Transport Package：Standard Wooden Case
  • Trademark：GOLD
  • Origin：Chongqing China(Mainland)

Base Info

  • Model NO.：GD2863
  • HS Code：9031809090
  • Production Capacity：500 Sets, Year

Description

ASTM D 2863Standard Test Method for Measuring the Minimum Oxygen Concentration to Support Candle-Like Combustion of Plastics (Oxygen Index)ISO 4589-2Plastics - Determination of burning behaviour by oxygen index - Part 2: Ambient- temperature test ISO 4589-3Plastics - Determination of burning behaviour by oxygen index - Part 3: Elevated-temperature test



Features:

1.Paramagnetic Cell to measure exact oxygen concentration.

2. Auto & Manual mode (Select control and analysis by personal computer or user).

3. Automatic Mass Flow Controller.

4. Precision display window on the software to facilitate easy reading of oxygen concentrations.

5. Specimen Holder facilitating separation and attachment of test sample.

6. Sample support suited to hard or smooth samples.

7. Shortest gas route to fast indicate test results.

8. DAQ System designed to display all test results to exactly match with each standard (It can be make stronger measuring and more correct & fine test result and also more powerful repeatable performance).

9. Foot switch controller to easily control the DAQ System.

10. Simple and compact design.

11. Portable ignition fixture with precise needle valve control the ignition flame height easily.

12. The oxygen concentration measurement range: 0 to 100%.



Specification:

Product NameASTM D 2863 Plastics Elevated-Temperature LOI Testing EquipmentSize600mm(w) * 370mm(D) * 350mm(H)Power220V, 60 Hz, 10.25AWeightWeight
