Lab Injection Molding Apparatus for Making Plastic Tensile Specimen

Jinan Xinghua Instruments Co., Ltd.
  • After-sales Service：12 Month Excellent After Service
  • Warranty：1 Year
  • Type：Test Sample Making Machine
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Touch Screen+ PLC Control

Base Info

  • Model NO.：XHS-39
  • Weight：100-500Kg
  • Power Source：AC220V
  • Transport Package：Plywood Case
  • Specification：Tensile Specimen, Bending Specimen...etc
  • Trademark：XHINSTRUMENTS
  • Origin：China
  • HS Code：9024800000
  • Production Capacity：5000 PCS, Year

Description

Control method

PLC(touch screen)HMI

Material Feeding Torque

105 N.M (motor control+ reducer)

Pressure

≥0.8Mpa

Displacement resolution

0.1mm

Displacement range

0-70mm

Material Feeding Speed

1-130rpm

Injection stroke

70mm(Excluding Mould)

Injection force

About 1800kg

Injection Weight

Max 30g

Locking Force

6T

Max Temperature

Zone 1 and 2 area, 3 area360°C

Power/Full Load

Single Phrase AC 220V±10%;50HZ;2200W

Screw Diameter

20mm

Column Span

                  280mmx186mm

Dimension

1700mm×500mm×950mm

Weight

380kgs


Lab Injection Molding Apparatus for Making Plastic Tensile SpecimenLab Injection Molding Apparatus for Making Plastic Tensile Specimen
1. How About Machines Calibration?
Answer: All machines is calibrated well in house before it is out of factory, XH Instruments  will provide you calibration report, if you need calibration certificate from third party, such as ISO 17025 certificate, we also can provide you with extra charge.
2. What about delivery way and delivery item?
Answer: Courier Express  Delivery, Sea  Delivery,  Air Delivery.
EXW Works, FOB, C&F, CIF, ClP, CPT, FCA, DDU.
3. How can I pay you?
Answer:Bank TT, Western Union, L/C, Paypal.
4. How about you after service?
Answer: XH Instruments will give a feedback within 24 hours.Warranty Period is 12 Months.
For problem caused by product quality within warranty period,XH Instruments will provide product maintenance, technical support, freight out and home as well as spare parts free of charge.
Problem not caused by product quality within warranty period or maintenance beyond warranty period is only charged for replaced parts. However, freight charges home and out are at customer' side (only the replaced part is charged if transportation of instrument is unnecessary).
