• Model NO.：WDS-100
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC220V
• Max Load：100kn
• Accuracy：1 Class
• Delivery Time：10 Working Days
• Tensile Space：600mm
• Certificate：CE ISO
• Standard：Astmd ISO
• Application：Tensile Compression Bending Shear Test
• Protection：with Overload, Overcurrent, Protection Net
• Mainframe：Aluminum Shell
• Transport Package：Standard Export Packing
• Specification：750*510*1900mm
• Trademark：HST
• Origin：China
• HS Code：9024101000
• Production Capacity：800 Sets Per Month

Basic Info.

Model NO. WDS-100 Accuracy Grade 1 Load Way Electronic Load Loading Method Static Load Display Digital Control Manual Control Weight 100-500Kg Power Source AC220V Max Load 100kn Accuracy 1 Class Delivery Time 10 Working Days Tensile Space 600mm Certificate CE ISO Standard Astmd ISO Application Tensile Compression Bending Shear Test Protection with Overload, Overcurrent, Protection Net Mainframe Aluminum Shell Transport Package Standard Export Packing Specification 750*510*1900mm Trademark HST Origin China HS Code 9024101000 Production Capacity 800 Sets Per Month

Product Description

Digital Universal Tensile Test Instrument/ Wire Tensile Strength Tester (WDS-100)1.Application:
It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing.
It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
2.Standard:
ASTM, ISO, DIN, GB and other international standards.
3.Main Technical Parameters:

Model	WDS-100
Max. Load	100 KN
Structure	Four-column Floor Model (Upper Is Tensile And Lower Is Compression)
Control Method	Single Chip Control
Load Accuracy	1 Class
Load Range	2%~100%F·S
Displacement Resolution	0.04um
Test Speed	1~200mm/min
Tensile Space	600mm (Can be customized)
Compression Space	600mm (Can be customized)
Test Width	450mm (Can be customized)
Power Supply	AC220V±10%, 50Hz (Can be customized)
Grips	Wedge Type, Plate Type And Other Grips As Customers' Demand
Weight	400 KG
Dimension	750*510*1900mm

4.Main Unit Feature:
4.1 Adopt floor structure,High Stiffness, lower for tensile, upper for compression,upper for tensile,
   lower for compression, double space. The beam is step less lifting.
4.2 Adopting ball screw drive, realize no clearance transmission,make sure the precision control of
   the test force and deformation speed.
4.3 The shiel plate with limit mechanism used to control the beam moving range, in order to avoid
   sensor damaged due to the moving distance is too large.
4.4 The table, moving beams is made of high quality precision machining steel plate , not only
   reduce the vibration generated by specimen fracture, but also improve the stiffness.
4.5 Three columns of mandatory orientation, make the main unit rigidity much improved, to further
   ensure the repeatability of measurement.
4.6 Adopt bolt type grip installation, make the grip replace easier.
4.7 Adopt AC servo driver and AC servo motor, with stable performance,more reliable.
   Have over-current, over-voltage, over speed, overload protection device.

5.Function Features:
5.1 Automatic calibration: system can automatically realize the accuracy of the calibration value.
5.2 After the sample broken, automatic stop.
5.3 Automatic display: Real-time display testing force, displacement, testing speed, peak value,
   testing status on one LCD.
5.4 Automatic return: beam automatic return to initial position when testing finished.
5.5 Breakage judgment: sample after fracture,beam automatic stop moving.
5.6 Limiting protection: Program control and Mechanical limiting protection.
5.7 Overload protection:When more than 3~5% of the rated load device automatically stop working
5.8 Automatic calculation: automatic calculation area after input sample diameter (round); Width,
   thickness (flat), sample gauge ect.
