3000kn/300ton Concrete Building Materials Compression Testing Machine

Jinan Kason Testing Equipment Co., Ltd.

After-sales Service：Standard
Warranty：1 Year
Max Diameter of Workpiece：2100mm
Mass Scope of Workpiece：4000kg
Type：Compression Testing Machine
Maxcapacity：>1000KN

Base Info

Model NO.：YES-3000
Accuracy Grade：1
Load Way：Mechanical Load
Loading Method：Static Load
Display：Digital
Control：Manual Control
Weight：500-1000Kg
Power Source：AC220V
Sample：Concrete,Cement
Resolution：0.01kn
Piston Route：50mm
Pressure Plate：250X250mm
Transport Package：Wooden Case
Specification：535X1110X1420mm
Trademark：Hensgrand or OEM
Origin：Jinan, Shandong
HS Code：9024800000
Production Capacity：500 Sets,Month

Description

Overview Product Description

1. Product Brief Introduction

YES Digital Display Compression Testing Machine CTM is used for compression strength detection for concrete, stone, cement, construction parts and other building materials. By which construction protection, such as railroad, road, bridge, port, high-rise etc can be ensured.
This kind of compression testing machine is welcomed by labs, research and develop institues, inspection agency, and universities. Conforms to GB/T, ISO, ASTM, DIN, JIS, etc.
2. Features
Easy to operate, without any environment requirements
Test data is displayed by digital meter
Suppors test data print
Protection hood to ensure operator safety
3. SpecificationsYES-1000YES-2000YES-3000Max. load1000kN2000kN3000kNClass1 class1 class1 classTesting space
regulating wayManual ball screw adjustControl wayManual control load wayOil source control cabinet structure formOne-piece bench oil source control cabinetRange of test force4% ~100%FSIndicating value accuracy±1%Piston route50mm50mm50mmMax piston speed//50mm/minRange between the working tables320mm320mm320mmPressure plates size250*250mm (Can be customized)DisplayLCDPower supply2.1KW AC 380VDetailed Photos
