- Model NO.:ESS-225LL5-G
- Power Source:AC380V
- Working Chamber Volume (L):225L
- Temp. Rate of Change Oc/Min:3-15
- Ramp Temp. Range:-70oc~+100oc(Rapid Temp. Change -40oc~+85ocfull Li
- Temp. Constancy:+,-3.0oc
- Colling Mode:Water Cooled
- Heater:Iron-Chrome Wire Heater
- Compressor:France Imported Tecumseh Semi-Hermetic Compressor
- Blower:Centerifugal Blower
- Power:AC380+,-10% 50Hz 3phase4wires+Groud Wires
- Standard Accessories:Sight Window, Cable Port, Baffle, Baffle Frame*2,
- Transport Package:Strong Plywood Case, Meet International Standard
- Specification:Standard and Customized
- Trademark:KOMEG
- Origin:Dongguan, China
- HS Code:90321000
- Production Capacity:1000 Sets,Year
Specifications | |
Model | ESS-SL |
225SL5 | 225SL10 | 408SL5 | 408SL10 | 1000SL5 | 1000SL10 | 1000SL15 |
Working Chamber Volume(L) | 225 | 408 | 1000 |
Temp Rate of Change( ºC/Min) | 5 | 10 | 5 | 10 | 5 | 10 | 15 |
Performance | -70ºC~+100ºC |
Rapid Temp Change -55ºC~+85ºC Full Linear Control |
Humidity Constancy | ±0.5ºC |
Temp Constancy | ±3.0ºC |
Exterior Material | Cold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless Steel |
Interior Material | Stainless Steel Plate(SUS 304) |
Insulation Material | Rigid Polyurethane Foam |
Safety Devices | over pressure,over heat and over current protection for compressor, over temp. protection, |
Compressor | Semi-Hermetic Compressor |
Cooling Mode | Water Cooled |
Control system | Balanced Temperature & Humidity Control System(BTC type) |
Heater | Iron-chrome wire heater |
Blower | Centrifugal Blower |
Observation Window | Glass incorporating heat generator |
Temp Sensor | Pt-100 |
Controller | Touch screen programmable controller |
Ambient Temp. | +5ºC~+35ºC |
Power | AC 380V/50Hz 3phase 5 wires+ Ground wire |
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
Specifications | |
Model | ESS-LL |
225LL5 | 225LL10 | 408LL5 | 408LL10 | 1000LL5 | 1000LL10 |
Working Chamber Volume(L) | 225 | 408 | 1000 |
Temp Rate of Change( ºC/Min) | 5 | 10 | 5 | 10 | 5 | 10 |
Performance | -70ºC~+100ºC |
Rapid Temp Change -40ºC~+85ºC Full Linear Control |
Humidity Constancy | ±0.5ºC |
Temp Constancy | ±3.0ºC |
Exterior Material | Cold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless Steel |
Interior Material | Stainless Steel Plate(SUS 304) |
Insulation Material | Rigid Polyurethane Foam |
Safety Devices | over pressure,over heat and over current protection for compressor, over temp. protection, |
Compressor | Semi-Hermetic Compressor |
Cooling Mode | Water Cooled |
Control system | Balanced Temperature & Humidity Control System(BTC type) |
Heater | Iron-chrome wire heater |
Blower | Centrifugal Blower |
Observation Window | Glass incorporating heat generator |
Temp Sensor | Pt-100 |
Controller | Touch screen programmable controller |
Ambient Temp. | +5ºC~+35ºC |
Power | AC 380V/50Hz 3phase 5 wires+ Ground wire |
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
