• Model NO.：GDPD-313M
• portable case size：395mm*295mm*105mm
• Total weight：2.7KG
• IP degree：54
• Screen：240*320 TFT screen
• Rated voltage：8.4V
• Charging output current：1A
• Transport Package：Standard Export Wooden Box
• Specification：178mm*75mm*30mm
• Trademark：HV Hipot
• Origin：China
• HS Code：9030849000
• Production Capacity：1000set,Year

Measurement range

0-65dB

Bandwidth

3-100MHz

Accuracy

±1dB

Max. pulse times per cycle

1000

Min. pulse times

1


        Ultrasonic sensor

Measurement range

-7dB~70dB

Resolution

1dB

Accuracy

±1dB

Sensitivity

-65dB

Center frequency

40.0±1.0KHz

Bandwidth

2.0KHz

        Ultrasonic wave condenser (OPTIONAL  EXTRNAL)

Gain

10dB

Sensor center frequency

40kHz

Sensor bandwidth

 2kHz

Laser sensor

5mW 650nm red laser; safety class LASS IIIA

Interface

4-core aviation plug

Cable

 2 m spring wire

        Serpentine probe ultrasonic sensor (OPTIONAL  EXTRNAL)

Sensor center frequency

40kHz

Sensor bandwidth

2kHz

Sensor sensitivity

-65dB

Interface

4-core aviation plug

Cable

2 m spring wire

        Battery

Built-in battery

Lithium battery, 8.4V, 1800mAh

Use time

About 8 hours

Charging time

About 4 hours

Protection

Over-voltage and over-current protection

        Charger

Rated voltage

8.4V

Output current

1A

Temperature

-20ºC-60ºC

Humidity

<80%

        Hardware

Shell

Monochrome molding plastic

Screen

240*320 TFT LCD screen

Control

6 buttons

Interface

Micro USB interface, charger port, headphone port, external port for collecting wave collector

Headphone

High fidelity noise canceling headphones

        Dimension

Size

178mm×75mm×30mm

Weight

0.25KG

Case size

399mm×295mm×105mm

Case weight

2.3KG

Total weight

2.7KG

        Working environment

Use temperature

-20ºC~50ºC

Environmental humidity

0-90%RH

IP class

54

Packing list

Main unit

TEV sensor(built-in)

Ultrasonic sensor(built-in)

Noise canceling headphone

Probe

Wave collector(Optional)

Charger

Power cord

User's guide

Factory test report
