• Model NO.：GD-2,500kV
• Loading Method：Dynamic Load
• Display：sound and light
• Control：Manual Control
• Weight：0-100Kg
• Power Source：9V Dry Battery
• Detectable Voltage Range：up to 500kV
• Power supply：9V stacked dry battery
• Quiescent current：<1uA
• Internal resistance：2MΩ
• Working current：80mA
• Working temperature：0ºC~40ºC
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030209000
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GD-2/500kV Loading Method Dynamic Load Display sound and light Control Manual Control Weight 0-100Kg Power Source 9V Dry Battery Detectable Voltage Range up to 500kV Power supply 9V stacked dry battery Quiescent current <1uA Internal resistance 2MΩ Working current 80mA Working temperature 0ºC~40ºC Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030209000 Production Capacity 2000PCS/Year

Product Description

I. General information

GD-2/500kV Voltage Detector is a high voltage detect tool, which is composed of signal device and insulated rod. Signal device adopt with integrated circuits, during the work, it can detect the electromagnetism strength of electrified body to determine the tested conductor if electriferous or not, and automatically start the voice circuit and light indicator.
It can detect over 6KV HV source if electriferous or not, different voltage level electroscope equip with different insulated rod, it can be detect up to 500KV voltage. Below 10kV, the signal device can be used as 220V LV electroscope without insulated  rod.
It is small size, light weight, simple to use and easy for carrying. It is widely used in Substations, Power plants, Industrial and Mining enterprises and Scientific Research Dept. Detecting Station and Electrical Maintenance Dept. for voltage checking and field work.
The insulated rod is high voltage moisture-proof insulated rod, accord with IEC/IC78 standard. It is moisture-proof, high temperature resistance, shock resistance, bending resistance and high insulation.

II. The performance of signal device
1. Working temperature: 0ºC~40ºC
2. Storage temperature: -10ºC~50ºC
3. Humidity: <85%
4. Power supply: 9V stacked dry battery
5. Quiescent current: <1uA
6. Internal resistance: 2MΩ
7. Working current: 80mA
8. Export: Sound and light

The signal device adopt with mask integrated, it is contact high voltage electroscope, automatically detect the electrified body if electriferous or not. When the measured voltage is higher than the electroscope trigger voltage, the signal device will start the
language circuit and warning: "Danger, electriferous! ", at the same time, there is a light at the bottom of signal device.

III. Technical data of electroscope

Rated voltage (KV)	Trigger voltage (KV)	Insulated  rod effective length (m)	Insulated  rod shrink length (m)	Insulated  rod stretch length (m)	Sections
10	1.5-4	0.7	0.26	0.8	4
35	5-14	0.9	0.32	1.35	5
110	16-44	1.3	1.1	3.0	3
220	33-88	2.1	1.1	4.0	4
330	50-130	3.1	1.1	4.0	4
400	60-160	3.4	1.1	5.0	5
500	75-200	4	1.1	6.0	5

Insulated rod effective length: the minimum distance of the hand hold insulated rod from electroscope.
Insulated rod shrink length: the length of insulated rod after shrinked.
Insulated rod stretch length: the length of insulated rod after extended.


IV.Application

1. Please check the signal device to make sure it is ok before using.
Check method: Press the self-check button of signal device, it will be warning "Danger, electriferous!", at the same time, there is a light at the bottom of signal device. Then the signal device is ok, can be used.
2.Fixed the signal device on insulated rod, pull out the insulated rod till tight.
3. Hold insulated rod, do not exceed the the handrail limit mark.
4. When detecting, please approach the probe to tested conductor slowly. If the signal device emit language and light, that means the tested conductor is eletriferous. Otherwise, if no language or light, that means the tested conductor is not eletriferous
5.For security consideration, you can test electriferous conductor first to see whether it is good or not, and then apply in formal use.
6. Is the electroscope is 6KV and 10KV, you can used as 220V Low voltage electroscope without insulated rod. The method is contact the button screw with hand, and contact the 220V live wire, the device will emit language and lights.

V. Insulated rod material characteristics (Table II)

Item	Unit	Index
Heat resistance no less	ºC	200
Impact resistance (vertical) no less	mpa/cm	147
Bending resistance (vertical) no less	mpa	343
Surface resistivity (soggy) no less	Ω	10×10¹¹
Volume resistivity (normal) no less	Ω/cm	10×10³¹

VI.The insulated rod withstand voltage (Table III)

Rated voltage of insulated rod	Withstand voltage	Detect length
10 KV	45 KV	0.4 m
35 KV	95 KV	0.6 m
110 KV	220 KV	1.0 m
220 KV	440 KV	1.8 m
330 KV	380 KV	2.8 m
400 kV	460 kV	3.3 m
500 KV	580 KV	3.7 m

VII. Attention
1. Electroscope trigger voltage will have some changes because of the influence of the ambient temperature and humidity, but the change will not exceed the scope of the data as above table I. Please note in use.
2. There are one section 9V stacked battery in the signal device. If the battery voltage drops, language volume will reduce . Please replace the battery by yourself.
3. Usually, the batteries can be used for 2 years.
