Komeg Basket 2-Zone Thermal Shock Chamber
Guangdong Komeg Industrial Co., Ltd.- Power Supply：AC380V ,AC220V 50Hz
- Certification：CE, ISO
- Warranty：1 Year
- Interrior(Cm)：W:61(Cm)H:77(Cm)D:61(Cm)
- Basket Material(Cm)：W:51(Cm)H:51(Cm)D:51(Cm)
- High Temp. Chamber：+60deg~+200deg
Base Info
- Model NO.：TST-A Series
- Pre-Heating Time：+60deg~+200deg Within 25min
- Low Temp.：-55deg~-10deg
- Test Chamber：-40deg~+150deg
- Transport Package：Strong Plywood Case, Meet International Standards
- Specification：Standard and Customized
- Trademark：KOMEG
- Origin：Dongguan, China
- HS Code：90321000
- Production Capacity：25 Sets Per Month
Description
Two-Zone Thermal Shock ChamberSpecifications Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available Model TST-A Series TST-B Series TST-D Series 72A 130A 226A 360A 500A 72B 130B 226B 360B 500B 72D 130D 226D 360D 500D Interior size W(mm) 410 520 610 710 810 410 520 610 710 810 410 520 610 710 810 H(mm) 560 670 770 830 710 560 670 770 830 710 560 670 770 830 710 D(mm) 410 520 610 770 860 410 520 610 770 860 410 520 610 770 860 Basket size W(mm) 300 410 510 610 710 300 410 510 610 710 300 410 510 610 710 H(mm) 300 410 510 730 610 300 410 510 730 610 300 410 510 730 610 D(mm) 300 410 510 510 730 300 410 510 510 730 300 410 510 510 730 Test weight ( KG ) 5 5 5 5 10 5 5 5 5 5 5 5 5 5 10 Low Temp. chamber -55 ºC~ -10 ºC -70 ºC~ -10 ºC -80 ºC~ -10 ºC Pre-heat time +20 ºC~ -55 ºC ,Within 60 min +20 ºC~ -70 ºC ,Within 60 min +20 ºC~ -80 ºC ,Within 60 mins Test. chamber -40 ºC~ +150 ºC -55 ºC~ +150 ºC -60 ºC~ +150 ºC High Temp. chamber +60 ºC~ +200 ºC Pre-heat time +60 ºC~ +200 ºC ,Within 25 min Recovery time High-Temp Exposure 30 min Low-Temp Exposure 30 min Recovery time within 5 min Transfer time within 10 seconds Safety device No fuse breaker, over pressure over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection Standard accessory Cable port(portΦ50mm)*1, shelves*2 Interior material Stainless steel plate ( SUS 304 ) Exterior material Baked painting steel or stainless steel(SUS304) Insulation material Rigid polyurethane Foam glass fiber wool Refrigeration system Water Cooled Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant ( HFC-507 and HFC-23 ) Controller Panel:7-inch LCD Touch panel , Chinese or English display selectable Operation model:Program or fix point running Memory capacity:120programs,1200steps , all repeat 999cycles , part repeat 99 cycles. Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit Input:Temp.:pt-100 Humidity:pt-100 or ~ 5V DCV Ambient TEmp. +5ºC~+35ºC Power AC 380±10% 50Hz ,3 phase 4 wires +Ground Wires
