100kv/200kv 4mA/2mA Portable DC Hipot Tester
Sansion Power Electric Co., Ltd.- Power Source：AC 110V,220V at Customized
- Output Voltage：Customized
- Power Supply：AC 220V±10%;50Hz
- Display Accuracy：±1%
- Ripple Factor：≤1%
- Transport Package：Plywood Case
Base Info
- Model NO.：SXZGF
- Specification：ISO9001 SGS
- Trademark：Sansion
- Origin：Wuhan, China
- HS Code：9030339000
- Production Capacity：100 Units
Description
60/2
100/2
150/3
160/2
180/2
200/5
250/2
100/200
3/2
200/300
3/2
Others
Output Voltage
(kV)
60
100
150
160
180
200
250
100/200
200/300
600~800kV fur customized
Output Current(mA)
2
2
3
2
2
5
2
3/2
3/2
Output Power(W)
120
200
450
320
360
1000
500
400
600
Charging Current
(mA)
3.0
3.0
12.0
3.0
3.0
3.0
3.0
4.5/3.0
4.5/3.0
Control Unit Weight(kg)
4.3
4.3
5.3
4.3
4.3
4.4
4.5
4.5
8.1
Doubler Size(mm)
Φ80
×500
Φ80
×620
Φ80
×770
Φ80
×770
Φ110
×770
Φ110
×770
Φ110
×820
Φ110
×800
Φ110
×1350
Doubler Weight(kg)
6.3
6.8
7.5
7.2
7.2
7.2
7.6
7.5
12.6
HV polarity:
Negative voltage polarity, Zero start, Continuously adjustable.
Power Supply:
AC 220V±10%;50Hz
Voltage measurement error:
1.0% ±1 digit, Max. resolution: 0.1%kV
Current measurement error:
1.0% ±1digit, Max. resolution: 0.1%uA
Overvoltage setting error:
≤1.0%
0.75 switching error:
≤0.5%
Ripple coefficient
≤1.0%
Voltage Stability:
Stochastic wave ≤0.5% when power wave is ±10%,
Duty:
Rated load: 30mins.;1.1 times rated voltage:10mins
Working Temperature:
-15ºC~50ºC
Relative Humidity:
When temperature is at 25ºC, less than 90%(no condensation)
Altitude:
Below 2500M
Warranty: One year quality guarantee after shipment.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
